UPERSERVER 6013P-8+ User's Manual
5-8

Connector Definitions

ATX Power Connection

The power
meets the SSI (Superset ATX) 20-
pin specification.
the orientation of the connector is
correct. See the table on the right
for pin definitions.

PWR_SEC Connection

In addition to the Primary ATX
power connector (above), the
Secondary 12v 8-pin J15 connec-
tor must also be connected to
your power supply. See the table
on the right for pin definitions.

NMI Button

The non-maskable interrupt button
header is located on pins 19 and
20 of JF2. Refer to the table on
the right for pin definitions.

Power LED

The Power LED connection is lo-
cated on pins 15 and 16 of JF2.
Refer to the table on the right for
pin definitions.

HDD LED

The HDD (IDE Hard Disk Drive) LED
connection is located on pins 13
and 14 of JF2. Attach the IDE hard
drive LED cable to display disk ac-
tivity. Refer to the table on the
right for pin definitions.
supply connector
Make sure that
AT X Power Supply 20-pin Connector
Pin N umber Definition
11 +3.3V
12 -12V
13 COM
14 PS_ON
15 COM
16 COM
17 COM
18 -5V
19 +5V
20 +5V
8-Pin +12v Power Supply
1 thru 4
5 thru 8
Definitions (JF2)
Pin
Number
19
20
PW R_LED Pin Definitions
Pin
Number
15
16
Number
5-12
Pin Number Definition
1 +3.3V
2 +3.3V
3 CO M
4 +5V
5 COM
6 +5V
7 CO M
8 PW -OK
9 5VSB
10 +12V
Connector (J15)
Pins Definition
Ground
+12v
NMI Button Pin
Definition
Control
Ground
(JF2)
Definition
Vcc
Control
H DD LED Pin
Definitions
(JF2)
Pin
Definition
13 Vcc
14 HD Active
