Wake-On-LAN

The Wake-On-LAN header is des-
ignated as WOL. See the table on
the right for pin definitions.
must enable the LAN Wake-Up set-
ting in BIOS to use this feature.
You must also have a LAN card
with a Wake-on-LAN connector
and cable.

Wake-On-Ring

The Wake-On-Ring header is des-
ignated WOR. This function al-
lows your computer to receive
and "wake-up" by an incoming call
to the modem when in sustpend
state. See the table on the right
for pin definitions. You must have
a WOR card and cable to use this
feature.

Keylock

The keyboard lock connection is lo-
cated on JP35. Utilizing this header
allows you to inhibit any actions
made on the keyboard, effectively
"locking" it.
Chapter 5: Advanced Serverboard Setup
You
5-17
W ake-On-LAN Pin
Definitions (W OL)
Pin
Number Definition
1 +5V Standby
2 Ground
3 W ake-up
W ake-on-Ring
Pin Definitions
(W OR)
Pin
Number Definition
1 Ground
2 W ake-up
