UPERSERVER 6013P-8+ User's Manual
Memory Support
The X5DPR-8G2+ only supports ECC registered DDR266/200 (PC2100/1600)
memory. If you are using 533 MHz FSB processors, you should use DDR266
SDRAM. If you are using 400 MHz FSB processors, you may use either DDR266
or DDR200 SDRAM. You should not mix DIMMs of different sizes and speeds.
See Figures 5-5a and 5-5b for installing and removing memory modules.
Figure 5-5a.
To Install: Insert module vertically and press down until it snaps into
place. Pay attention to the bottom notch.
To Remove: Use your thumbs to gently push each release tab outward
to free the DIMM from the slot.
Side View of DIMM Installation into Slot
Figure 5-5b. Top View of DIMM Slot
5-8
