  • Page 1 ® UPER 6013P-T UPER ERVER USER’S MANUAL 1.0a...
  • Page 2 The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product. Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document.

  • Page 3: About This Manual

    Chapter 2: Server Installation This chapter describes the steps necessary to install the SuperServer 6013P-T into a rack and check out the server configuration prior to power- ing up the system. memory components, this chapter will refer you to the appropriate sections of the manual for their installation.
  • Page 4 You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6013P-T. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X5DPR-TG2+ serverboard, including the locations and functions of connectors, headers and jumpers.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    Choosing a Setup Location ... 2-2 Rack Precautions ... 2-2 Server Precautions ... 2-2 Installing the SuperServer 6013P-T into a Rack ... 2-3 Identifying the Sections of the Rack Rails ... 2-3 Installing the Chassis Rails ... 2-4 Installing the Rack Rails ... 2-4 Installing the Server into the Rack ...
  • Page 7 Serial ATA Drive Carrier LED ... 3-3 Chapter 4: System Safety Electrical Safety Precautions ... 4-1 General Safety Precautions ... 4-2 ESD Precautions ... 4-3 Operating Precautions ... 4-4 Chapter 5: Advanced Serverboard Setup Handling the X5DPR-TG2+ Serverboard ... 5-1 PGA Processor and Heatsink Installation ...
  • Page 8 UPER ERVER 6013P-T Manual Third Power Supply Fail Header ... 5-16 Chassis Intrusion ... 5-16 Wake-On-LAN ... 5-17 Wake-On-Ring ... 5-17 Keylock ... 5-17 Jumper Settings ... 5-18 Explanation of Jumpers ... 5-18 CMOS Clear ... 5-18 GLAN Enable/Disable ... 5-19 VGA Enable/Disable ...
  • Page 9 Security ... 7-15 Power ... 7-17 Boot ... 7-19 PIR ... 7-20 Exit ... 7-22 Appendices: Appendix A: BIOS POST Messages ... A - 1 Appendix B: BIOS Post Codes ... B-1 Appendix C: Software Installation ... D-1 Appendix D: System Specifications ... C-1 Table of Contents...
  • Page 10 UPER ERVER 6013P-T User's Manual Notes...

  • Page 11: Overview

    SuperServer 6013P-T. (www.supermicro.com) In addition to the mainboard and chassis, various hardware components may have been included with your SuperServer 6013P-T, as listed below: Two (2) 1U CPU heatsinks (SNK-0040) One (1) 3.5" slim floppy drive...

  • Page 12: Mainboard Features

    One (1) CD containing drivers and utilities SuperServer 6013P-T User's Manual Mainboard Features At the heart of the SuperServer 6013P-T lies the X5DPR-TG2+, a dual Intel Xeon processor serverboard designed to provide maximum performance. Below are the main features of the X5DPR-TG2+.

  • Page 13: Pci Expansion Slots

    The X5DPR-TG2+ supports single or dual Intel 604/603-pin Xeon processors of up to 3.06 GHz at a 533/400 MHz FSB. section of our web site for a complete listing of supported processors (http://www.supermicro.com/TechSupport.htm). Memory The X5DPR-TG2+ has six 184-pin, DIMM slots that can support up to 12 GB of low-profile, registered ECC DDR266/200 (PC2100/1600) SDRAM.

  • Page 14: Other Features

    UPER ERVER 6013P-T Manual Onboard Controllers/Ports The X5DPR-TG2+ includes one floppy drive controller and two onboard IDE controllers, which support up to four hard drives or ATAPI devices. Backpanel I/O ports include one COM port, two USB ports, PS/2 mouse and keyboard ports and a video (monitor) port.

  • Page 15: Server Chassis Features

    When configured as a SuperServer 6013P-T, the SC813 chassis includes a 500W cold-swap power supply. Serial ATA Subsystem For the 6013P-T, the SC813T chassis was designed to support four Serial ATA hard drives, which are hot-swappable units. Note: The operating system you use must have RAID support to enable the hot-swap capability of the Serial ATA drives.

  • Page 16: Cooling System

    UPER ERVER 6013P-T Manual Keyboard Port Mouse Port Low Profile PCI Slot Standard PCI Slot USB Ports COM1 Port Ethernet Ports VGA Port Figure 1-2. I/O Backplane Cooling System The SC813T chassis' revolutionary cooling design has been optimized to provide sufficient cooling for dual Xeon configurations.

  • Page 17: Contacting Supermicro

    Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 18 UPER ERVER 6013P-T Manual Notes...

  • Page 19: Chapter 2: Server Installation

    Decide on a suitable location for the rack unit that will hold the SuperServer 6013P-T. It should be situated in a clean, dust-free area that is well venti- lated. Avoid areas where heat, electrical noise and electromagnetic fields are generated.

  • Page 20: Choosing A Setup Location

    UPER ERVER 6013P-T Manual Choosing a Setup Location - Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). - Leave approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.

  • Page 21: Installing The Superserver 6013P-T Into A Rack

    Installing the SuperServer 6013P-T into a Rack This section provides information on installing the SuperServer 6013P-T into a rack unit with the rack rails provided. If the 6013P-T has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6.

  • Page 22: Installing The Chassis Rails

    UPER ERVER 6013P-T Manual Installing the Chassis Rails Two of the chassis rails (Chassis Rail 1) should have already been preattached - one to each side of the chassis. Attach the second set of chassis rails (Chassis Rail 2) directly to the chassis with the screws provided.

  • Page 23: Installing The Server Into The Rack

    Chapter 2: Server Installation Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. Do this by lining up the rear of the chassis rails with the front of the rack rails. Slide the chassis rails into the rack rails, keeping the pressure even on both sides (you may have to depress the locking tabs when inserting).

  • Page 24: Installing The Server Into A Telco Rack

    ERVER 6013P-T Manual Installing the Server into a Telco Rack If you are installing the SuperServer 6013P-T into a Telco type rack, follow the directions given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.

  • Page 25: Checking The Serverboard Setup

    Checking the Serverboard Setup After you install the 6013P-T in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. 1. Accessing the inside of the 6013P-T (see Figure 2-5): First, release the retention screws that secure the unit to the rack.
  • Page 26 UPER ERVER 6013P-T Manual Figure 2-5. Accessing the Inside of the SuperServer 6013P-T (with optional front bezel shown) 6. Check all cable connections and airflow: Make sure all power and data cables are properly connected and not blocking the chassis airflow. See Chapter 5 for details on cable connec- tions.

  • Page 27: Checking The Drive Bay Setup

    Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the Serial ATA drives and SCA backplane have been properly installed and all conn- ections have been made. 1. Accessing the drive bays: All drives are accessable from the front of the server. For servicing the CD-ROM and floppy drives, you will need to remove the top chassis cover.
  • Page 28 UPER ERVER 6013P-T Manual Notes 2-10...

  • Page 29: Chapter 3: System Interface

    Overview There are several LEDs on the control panel as well as others on the Serial ATA drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components. There are also two buttons on the chassis control panel and an on/off switch on the power supply.

  • Page 30: Control Panel Leds

    Indicates network activity on GLAN2 when flashing . NIC1 NIC1: Indicates network activity on GLAN1 when flashing. HDD: Indicates IDE channel activity. On the SuperServer 6013P-T this light indicates SATA and CD-ROM drive activity when flashing. You should also check to make sure The air seals are...

  • Page 31: Power

    Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Serial ATA Drive Carrier LED Each Serial ATA drive carrier has a green LED. green LED (on the front of the Serial ATA drive carrier) indicates drive activity.
  • Page 32 UPER ERVER 6013P-T User's Manual Notes...

  • Page 33: Chapter 4: System Safety

    Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6013P-T from damage: Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 34: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: Keep the area around the SuperServer 6013P-T clean and free of clutter. The SuperServer 6013P-T weighs approximately 39 lbs (17.7 kg) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.

  • Page 35: Esd Precautions

    After accessing the inside of the system, close the system back up and secure it to the rack unit with the retention screws after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.

  • Page 36: Operating Precautions

    Care must be taken to assure that the chassis cover is in place when the 6013P-T is operating to ensure proper cooling. Out of warranty damage to the 6013P-T system can occur if this practice is not strictly followed. Figure 4-1.

  • Page 37: Chapter 5: Advanced Serverboard Setup

    Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X5DPR-TG2+ serverboard, connect the data and power cables and install add-on cards. scribed and a layout and quick reference chart are included in this chapter. Remember to close the chassis completely when you have finished working on the serverboard to protect and cool the system sufficiently.

  • Page 38: Pga Processor And Heatsink Installation

    UPERSERVER 6013P-T User’s Manual PGA Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up.
  • Page 39 4. Apply the proper amount of thermal compound to the CPU die and place the heatsink directly on the CPU so that the four mounting holes are aligned with those on the chassis. Make sure the heatsink sits completely flat on the CPU - if not completely flat, the space between the two will degrade the heat dissipation function of the heatsink, which may cause the processor to overheat.
  • Page 40 UPERSERVER 6013P-T User’s Manual Figure 5-2. Heatsink Installation...

  • Page 41: Connecting Cables

    Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed in preconfigured systems to prevent them from block- ing the flow of cooling air that moves through the system from front to back.

  • Page 42: Connecting The Control Panel

    UPERSERVER 6013P-T User’s Manual Connecting the Control Panel JF2 contains header pins for various front control panel connectors. Figure 5-3 for the pin locations of the various front control panel buttons and LED indicators. Please note that even and odd numbered pins are on opposite sides of each header.

  • Page 43: I/O Ports

    Bank 1 (both DIMM#1A and DIMM#1B). The memory scheme is interleaved so you must install two modules at a time, beginning with Bank 1, then Bank 2 and so on. The 6013P-T requires the use of low-profile memory. 2. Insert each DIMM module vertically into its slot.
  • Page 44 UPERSERVER 6013P-T User’s Manual Memory Support The X5DPR-TG2+ only supports ECC registered DDR266/200 MHz SDRAM memory. If you are using 533 MHz front side bus processors(s), you must use DDR266 SDRAM. processors(s), you may use either DDR266 or DDR200 SDRAM.

  • Page 45: Adding Pci Cards

    Adding PCI Cards PCI slots: The X5DPR-TG2+ has one 64-bit 133 MHz PCI-X slot for a full-length (standard) PCI card and one slim 64-bit 66 MHz PCI slot. The 64-bit 133 MHz PCI-X slot should have a butterfly riser card installed, which can accept one standard sized PCI card and one low profile PCI card (see Figures 5-6a and 5-6b).

  • Page 46: X5Dpr-Tg2+ Layout

    UPERSERVER 6013P-T User’s Manual Serverboard Details Figure 5-7. SUPER X5DPR-TG2+ Layout Keyboard DIMM #1A Mouse DIMM #1B USB0/1 DIMM #2A DIMM #2B DIMM #3A DIMM #3B GLAN1 GLAN2 82546EB BIOS Rage XL PCI Graphics Controller JP35 JP24 Notes: The IPMI socket is an optional feature.

  • Page 47: X5Dpr-Tg2+ Quick Reference

    X5DPR-TG2+ Quick Reference Jumper Description JBT1 CMOS Clear Speaker Enable (Pins 6-7) GLAN Enable/Disable VGA Enable/Disable Power Fail Alarm En/Disable JP37 Watchdog Enable/Disable JP38 Front Side Bus Speed JPS1,JPS2 SATA1/2 Enable/Disable Connector Description ATX POWER (Primary) ATX 20-pin Power Connector COM1/COM2 COM1/COM2 Serial Port Connectors CPU1/CPU2...

  • Page 48: Connector Definitions

    UPERSERVER 6013P-T User’s Manual Connector Definitions ATX Power Connection power supply meets the SSI (Superset ATX) 20- pin specification. Make sure that the orientation of the connector is correct. See the table on the right for pin definitions. PWR_SEC Connection...

  • Page 49: Nic1 Led

    Refer to the table on the right for pin definitions. This only applies to redundant power supplies and so does not apply to the 6013P-T. Reset Button The Reset Button connection is lo- cated on pins 3 and 4 of JF2. At- tach it to the hardware reset switch on the computer case.

  • Page 50: Power Button

    UPERSERVER 6013P-T User’s Manual Power Button The Power Button connection is located on pins 1 and 2 of JF2. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button (see the Power Button Mode setting in BIOS).

  • Page 51: Serial Ports

    Serial Ports The COM1 serial port is located beside the mouse port. table on the right for pin defini- tions. The COM2 connector is a header on the serverboard (see serverboard layout for location). ATX PS/2 Keyboard and PS/2 Mouse Ports The ATX PS/2 keyboard and the PS/2 mouse ports are located at J28 and J29, respectively.

  • Page 52: Power Led/Speaker/Nmi

    Note: This feature is only avail- able when using Supermicro power supplies and so does not apply to the 6013P-T. Chassis Intrusion A Chassis Intrusion header is lo- cated at JL1. Attach the appropri- ate cable to inform you of a chas- sis intrusion.

  • Page 53: Wake-On-Lan

    Wake-On-LAN The Wake-On-LAN header is des- ignated as WOL. See the table on the right for pin definitions. must enable the LAN Wake-Up set- ting in BIOS to use this feature. You must also have a LAN card with a Wake-on-LAN connector and cable.

  • Page 54: Jumper Settings

    UPERSERVER 6013P-T User’s Manual Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used choose optional settings. create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.

  • Page 55: Glan Enable/Disable

    GLAN Enable/Disable Change the setting of jumper JD4 to enable or disable the onboard GLAN ports (GLAN1 and GLAN2) on the serverboard. See the table on the right for jumper settings. The default setting is enabled VGA Enable/Disable JP4 allows you to enable or disable the VGA port.

  • Page 56: Watch Dog Enable/Disable

    UPERSERVER 6013P-T User’s Manual Watch Dog Enable/Disable The Watch Dog jumper (located on JP37) allows you to enable or dis- able the Watch Dog feature. default position is open to disable the Watch Dog timer. abled, Watch Dog can reboot your PC if an application is "hung up"...

  • Page 57: Floppy Connector

    5-11 Floppy/Hard Disk Drive and SATA Connections Note the following when connecting the floppy and hard disk drive cables: • The floppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1. •...

  • Page 58: Ide Connectors

    UPERSERVER 6013P-T User’s Manual IDE Connectors There are no jumpers to configure the onboard IDE#1 and #2 connectors. See the table on the right for pin definitions. SATA Connectors There are no jumpers to configure onboard SATA0(JS1), SATA1(JS2), SATA2(JS3), SATA3(JS4), connectors.

  • Page 59: Chapter 6: Advanced Chassis Setup

    Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC813T chassis. For component installation, follow the steps in the order given to eliminate the most common problems encoun- tered. If some steps are unnecessary, skip ahead to the next step. Tools Required The only tool you will need to install components and perform maintenance is a Philips screwdriver.

  • Page 60: Control Panel

    UPER ERVER 6013P-T Manual Slim-Line CD-ROM Drive Figure 6-1. Control Panel The control panel (located on the front of the chassis) must be connected to the JF2 connector on the serverboard to provide you with system status indications. A ribbon cable has bundled these wires together to simplify the connection.

  • Page 61: System Fans

    System Fans Two 10-cm blower fans provide all the cooling needed for the SuperServer 6013P-T. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 62: Drive Bay Installation/Removal

    UPER ERVER 6013P-T Manual 10-cm Blower Fans Figure 6-2. System Cooling Fans (with optional front bezel shown) Drive Bay Installation/Removal Removing the Front Bezel If your system has a front bezel (optional) attached to the chassis, you must first remove it to gain access to the drive bays. To remove the bezel, first unlock the front of the chassis then press the release knob (see Figure 6-3).

  • Page 63: Accessing The Drive Bays

    Serial ATA drives. Proceed to the next step for instructions. CD-ROM/Floppy Disk Drives: For installing/removing a CD-ROM or floppy disk drive, you will need to gain access to the inside of the 6013P-T by removing the top cover of the chassis. Proceed to the "CD-ROM and Floppy Drive Installation"...

  • Page 64: Serial Ata Drive Installation

    UPER ERVER 6013P-T Manual Serial ATA Drive Installation Mounting a Serial ATA drive in a drive carrier The Serial ATA drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow for the Serial ATA drive bays. For this reason, even empty carriers without Serial ATA drives installed must remain in the chassis.
  • Page 65 Chapter 6: Advanced Chassis Setup Installing/removing hot-swap SATA drives: The SATA drive carriers are all easily accessible at the front of the chassis. These hard drives are hot-pluggable, meaning they can be removed and installed without powering down the system. To remove a carrier, push the release button located beside the drive LEDs.

  • Page 66: Cd-Rom And Floppy Drive Installation

    CD-ROM and Floppy Drive Installation The top cover of the chassis must be opened to gain full access to the CD- ROM and floppy drive bays. The 6013P-T accomodates only slim-line CD- ROM drives. Side mounting brackets are needed to mount a slim-line CD- ROM drive in the 6013P-T server.

  • Page 67: Power Supply

    Power Supply The SuperServer 6013P-T has a single 500 watt power supply, which is auto-switching capable. This enables it to automatically sense and operate with either a 100v or 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
  • Page 68 UPER ERVER 6013P-T Manual Figure 6-6. Removing/Replacing the Power Supply (with optional front bezel shown) 6-10...

  • Page 69: Chapter 7: Bios

    Please refer Manual Download <http://www.supermicro.com> for any changes to BIOS that may not be reflected in this manual. System BIOS The BIOS is the Basic Input Output System used in all IBM ®...

  • Page 70: Running Setup

    UPER ERVER 6013P-T Manual Running Setup *Default settings are in bold text unless otherwise noted. The BIOS setup options described in this section are selected by choos- ing the appropriate text from the main BIOS Setup screen. All displayed text is described in this section, although the screen display is often all you need to understand how to set the options (see on next page).

  • Page 71: Main Bios Setup Menu

    Main BIOS Setup Menu Main Advanced System Time System Date Legacy Diskette A: Legacy Diskette B: Primary Master Primary Slave Secondary Master Secondary Slave System Memory Extended Memory ↑↓ F1 Help Select Item ↔ Esc Exit Select Menu Main Setup Features System Time To set the system date and time, key in the correct information in the appropriate fields.

  • Page 72: Legacy Diskette A

    UPER ERVER 6013P-T Manual Legacy Diskette A This setting allows the user to set the type of floppy disk drive installed as diskette A. The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB, 3.5 in and 2.88MB 3.5 in.
  • Page 73 Type Selects the type of IDE hard drive. The options are Auto (allows BIOS automatically determine the hard drive's capacity, number of heads, etc.), a number from 1-39 to select a predetermined type of hard drive, CD-ROM and ATAPI Removable. Multi-Sector Transfers Select the number of transfer sectors.

  • Page 74: Advanced Setup

    UPER ERVER 6013P-T Manual Advanced Setup Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. The items with a triangle beside them have sub menus that can be accessed by highlighting the item and pressing <Enter>.
  • Page 75 Chapter 7: BIOS PCI/PnP Configuration Access the submenu to make changes to the following settings. Onboard LAN1 OPROM Configure Enabling this option provides the ability to boot from LAN1. The options are Enabled and Disabled. Onboard LAN2 OPROM Configure Enabling this option provides the ability to boot from LAN2. The options are Enabled and Disabled.
  • Page 76 UPER ERVER 6013P-T Manual PCI Slot Configuration PCI/PCIX Frequency (Slot 1-3) Use this setting to change the speed of PCI/PCIX slots 1 though 3. Options are Auto, 33 MHz, 66 MHz, 100 MHz and 133 MHz. PCI/PCIX Frequency (Slot 4) Use this setting to change the speed of PCI/PCIX slot 4.
  • Page 77 Large Disk Access Mode This setting determines how large hard drives are to be accessed. The options are DOS or Other (for Unix, Novellle NetWare and other operating systems). Local Bus IDE Adapter Use this setting to enable the integrated local bus IDE adapter. Options are Disable, Primary, Secondary and Both.
  • Page 78 UPER ERVER 6013P-T Manual Serial Port A This setting allows you to assign control of serial port A. The options are Enabled (user defined), Disabled and Auto (BIOS controlled). Base I/O Address Select the base I/O address for serial port A. The options are 3F8, 2F8, 3E8 and 2E8.
  • Page 79 Base I/O Address Select the base I/O address for the parallel port: 378, 278 or 3BC. Interrupt Select the IRQ (interrupt request) for the parallel port. Options are IRQ5 and IRQ7. Mode Specify the parallel port mode. Options are Output Only, Bi-directional, EPP and ECP.
  • Page 80 UPER ERVER 6013P-T Manual ECC Configuration This setting lets you enable or disable ECC (Error Correction and Checking). The options are ECC and Disabled. ECC Error Type This setting lets you select which type of interrupt will be activated as a result of an ECC error.
  • Page 81 Chapter 7: BIOS Split Lock Operations This setting allows you to Enable or Disable split lock operations. Hyper-threading This setting allows you to Enable or Disable hyper-threading. Enabling hyper-threading results in increased CPU performance. L3 Cache This setting allows you to Enable or Disable the L3 cache. DMI Event Logging Access the submenu to make changes to the following settings.
  • Page 82 UPER ERVER 6013P-T Manual Clear All DMI Event Logs Select Yes and press <Enter> to clear all DMI event logs. Console Redirection Access the submenu to make changes to the following settings. COM Port Address Specifies to redirect the console to On-board COMA or On-board COMB.

  • Page 83: Security

    Security Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. displayed by highlighting the setting using the arrow keys and pressing <Enter>. All Security BIOS settings are described in this section. Main Advanced Supervisor Password Is:...
  • Page 84 UPER ERVER 6013P-T Manual Set Supervisor Password When the item "Set Supervisor Password" is highlighted, hit the <Enter> key. When prompted, type the Supervisor's password in the dialogue box to set or to change supervisor's password, which allows access to BIOS.

  • Page 85: Power

    Power Choose Power from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Power setting options are displayed by highlighting the setting using the arrow keys and pressing <Enter>. All Power BIOS settings are described in this section. Main Advanced ACPI Mode:...
  • Page 86 UPER ERVER 6013P-T Manual Suspend Timeout Use this setting to specify the period of system inactivity to transpire before entering the suspend state. Options are Off, 5 min, 10 min, 15 min, 20 min, 30 min, 40 min and 60 min.

  • Page 87: Boot

    Boot Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Highlighting a setting with a + or - will expand or collapse that entry. See details on how to change the order and specs of boot devices in the Item Specific Help window.

  • Page 88: Pir

    UPER ERVER 6013P-T Manual Choose PIR from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. The items with a triangle beside them have sub menus that can be accessed by highlighting the item and pressing <Enter>.
  • Page 89 Processor Info ROM Data Highlight this and hit <Enter> to see PIR data on the following items: Header Info Processor Data Processor Core Data L3 Cache Data Package Data Part Number Data Thermal Reference Data Feature Data Other Data OEM Data Hardware Monitor Logic Highlight this and hit <Enter>...

  • Page 90: Chassis Fan

    UPER ERVER 6013P-T Manual Chassis Fan 2 Processor Vcore 3.3V Standby 3.3V Vcc 5V Vcc 12V Vcc 1.8V Vcc -12V Vcc Exit Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. All Exit BIOS settings are described in this section.
  • Page 91 Chapter 7: BIOS Exit Saving Changes Highlight this item and hit <Enter> to save any changes you made and to exit the BIOS Setup utility. Exit Discarding Changes Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any changes you may have made.
  • Page 92 UPER ERVER 6013P-T Manual Notes 7-24...

  • Page 93: Appendix Abios Post Messages

    Appendix A: BIOS POST Messages Appendix A BIOS POST Messages During the Power-On Self-Test (POST), the BIOS will check for problems. If a problem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages.
  • Page 94 UPER ERVER 6013P-T Manual System CMOS checksum bad - Default configuration used System CMOS has been corrupted or modified incorrectly, perhaps by an application program that changes data stored in CMOS. The BIOS installed Default Setup Values. If you do not want these values, enter Setup and enter your own values.
  • Page 95 Appendix A: BIOS POST Messages System cache error - Cache disabled RAM cache failed and BIOS disabled the cache. On older boards, check the cache jumpers. You may have to replace the cache. See your dealer. A disabled cache slows system performance considerably. CPU ID: CPU socket number for Multi-Processor error.
  • Page 96 UPER ERVER 6013P-T Manual Fixed Disk n Fixed disk n (0-3) identified. Invalid System Configuration Data Problem with NVRAM (CMOS) data. I/O device IRQ conflict I/O device IRQ conflict error. PS/2 Mouse Boot Summary Screen: PS/2 Mouse installed. nnnn kB Extended RAM Passed Where nnnn is the amount of RAM in kilobytes successfully tested.
  • Page 97 Appendix A: BIOS POST Messages Parity Check 2 nnnn Parity error found in the I/O bus. BIOS attempts to locate the address and display it on the screen. If it cannot locate the address, it displays ????. Press <F1> to resume, <F2> to Setup, <F3> for previous Displayed after any recoverable error message.
  • Page 98 UPER ERVER 6013P-T Manual Notes...

  • Page 99: Appendix Bbios Post Codes

    BIOS POST Codes This section lists the POST (Power On Self Test) codes for the PhoenixBIOS. POST codes are divided into two categories: recoverable and terminal. Recoverable POST Errors When a recoverable type of error occurs during POST, the BIOS will display an POST code that describes the problem.
  • Page 100 UPER ERVER 6013P-T Manual POST Code Description 8254 timer initialization 8237 DMA controller initialization Reset Programmable Interrupt Controller 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Set ES segment register to 4 GB Auto size DRAM Initialize POST Memory Manager...
  • Page 101 POST Code Description Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1 Configure advanced cache registers Initialize Multi Processor APIC Enable external and CPU caches Setup System Management Mode (SMM) area Display external L2 cache size Load custom defaults (optional) Display shadow-area message...
  • Page 102 UPER ERVER 6013P-T Manual POST Code Description Check for SMART Drive (optional) Shadow option ROMs Set up Power Management Initialize security engine (optional) Enable hardware interrupts Determine number of ATA and SCSI drives Set time of day Check key lock...
  • Page 103 POST Code Description Re-map I/O and memory for PCMCIA Initialize digitizer and display message Unknown interrupt The following are for boot block in Flash ROM POST Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O Check force recovery boot Checksum BIOS ROM...
  • Page 104 UPER ERVER 6013P-T Manual Notes...

  • Page 105: Appendix C: Software Installation

    Image SATA RAID driver before you install the Windows operating system and other software drivers. The necessary drivers are all included on the Supermicro CDs that came packaged with your system. C-1 Installing SATA Driver for Silicon Image SATA Controller...
  • Page 106 SATA RAID Configuration Utility, at least two SATA hard drives must be installed in the system. 4. The Supermicro CD-ROM included with the system includes two SATA RAID drivers for use with Windows OS. If "SATA RAID Feature" is enabled in BIOS, use the RAID driver.

  • Page 107: Creating A Raid Set

    Appendix C: Software Installation I. Creating a RAID Set a. In the main menu (see screen shown below), use the up and down arrow keys to highlight the item Create a RAID Set and press the <Enter> key to select this feature b.
  • Page 108 UPER ERVER 6013P-T Manual Creating a Striped RAID Set (RAID 0) Automatically a. When the screen on the previous page appears, select "Striped" and hit the <Enter> key. Then the following screen will appear: b. Here, you can choose to configure RAID either automatically or manu- ally.
  • Page 109 Appendix C: Software Installation Manually a. When the screen shown on the previous page appears, select "Manual configuration" and hit the <Enter> key to access the screen below: b. In this screen, you can configure the first HDD to be the Primary Master or the Secondary Master.
  • Page 110 UPER ERVER 6013P-T Manual c. When the above screen appears, configure the 2nd HDD by highlighting your selection and pressing the <Enter> key. The following screen will appear:...
  • Page 111 Appendix C: Software Installation d. The above screen lets you determine the size for the Striped (RAID 0) set. Use the up and down arrow keys to make the selection and press the <Enter> key. Once you have set the size for RAID 0, Striped RAID is cre- ated.
  • Page 112 UPER ERVER 6013P-T Manual c. When the above screen appears, use the up and down arrow keys to highlight "Auto Configuration" and press the <Enter> key if you wish to create Mirrored RAID Set automatically. If you wish to configure the Mir- rored RAID set manually, select "Manual Configuration"...
  • Page 113 Appendix C: Software Installation d. When the above screen appears, you can decide if you want the Primary Master or the Secondary Master to be the source drive. Use the up and down arrow keys to make your selection and press the <Enter> key. Once you have made your selection of the source drive and pressed the <Enter>...

  • Page 114: Deleting A Raid Set

    UPER ERVER 6013P-T Manual II. Deleting a RAID Set a. If you wish to delete a RAID set that was created earlier, use the up and down arrow keys to select "Delete RAID Set" in the main menu (as shown on p.
  • Page 115 Appendix C: Software Installation c. When the above screen appears and you are prompted with "Are you sure? Y(es)/N(o)?" to verify your selection, type Y or N (to verify or cancel the selection). Once you've typed "Y" and press the <Enter> key the RAID set specified is deleted.

  • Page 116: Resolving Conflicts

    UPER ERVER 6013P-T Manual b. In the above menu, follow the instructions given to complete the process of rebuilding a Mirrored set. Once the Mirrored Set is rebuilt, press the <Esc> key to return the main menu. IV. Resolving Conflicts a.

  • Page 117: Low Level Formatting

    Appendix C: Software Installation b. Once the above menu appears, follow the instructions given to complete the process of Resolving Conflicts. When completed, press the <Esc> key to return the main menu. V. Low Level Formatting Note: A Low Level Format will cause the Hard Drive to be completely refor- matted.
  • Page 118 UPER ERVER 6013P-T Manual b. When the above screen appears, use the up and down arrow keys to specify the drive you wish to reformat and press the <Enter> key. The following screen will appear: c. When prompted "Are you sure? Y/N?", type Y to confirm or N to cancel the selection.

  • Page 119: Installing The Operating System

    After Windows OS Installation is completed, the system will automati- cally reboot. i. Insert Supermicro's CD that came with the package into the CD Drive during the system reboot, and the following screen will appear: j. When the following screen appears, you are ready to install other software programs and drivers.
  • Page 120 UPER ERVER 6013P-T Manual C-16...
  • Page 121 C-3 Installing Other Software Programs and Drivers A. Installing Drivers other than Silicon Image's 3112 SATA Host Controller Driver After you've installed Windows Operating System, a screen as shown be- low will appear. You are ready to install software programs and that have not yet been installed.
  • Page 122 UPER ERVER 6013P-T Manual B. Installing Silicon Image's Serial ATA RAID Software Program 1. After you've installed Windows Operating System, a screen as shown above will appear. To install Silicon Image's SATA RAID software, double click the icon to the right of "Sil SATA RAID" as shown above. Then, the screen as shown below will appear: 2.
  • Page 123 3. When the screen shown above appears, you are asked to choose the location where you want the destination location and click "Next". The following screen will appear: 4. When the screen shown above appears, the installation of the SATA RAID Software is completed.
  • Page 124 UPER ERVER 6013P-T Manual 5. When the screen shown above appears, it indicates that you have exited the SATA RAID Program, and have retuned to the Windows OS environment. If you want to access the SATA RAID Program from the Windows OS environment, double click "SATA RAID"...

  • Page 125: Supero Doctor

    Appendix C: Software Installation C. Supero Doctor III The Supero Doctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 126 Supero Doctor III Interface Display Screen-II (Remote Control) (*Note: SD III Software Revision 1.0 can be downloaded from our Website at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/ Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend Supero Doctor II.) C-22...
  • Page 127 Appendix C: Software Installation Notes C-23...

  • Page 128: Appendix D: System Specifications

    Serial ATA Controller Two Silicon Image controllers (Sil ATA (RAID 0,1) Serial ATA Backplane Controller Supermicro CSE SATA-813 Serial ATA Drive Bays Four (4) drive bays to house four (4) standard Serial ATA drives Peripheral Drive Bays One (1) slim 3.5" floppy drive One (1) slim CD-ROM drive Four (4) 3.5"...
  • Page 129 UPER ERVER 6013P-T Manual Expansion Slots (provided with butterfly riser card) One (1) 64-bit 133 MHz standard PCI-X slot and one (1) 64-bit 66 MHz low profile PCI slot Motherboard Model: X5DPR-TG2+ (Extended ATX form factor) Dimensions: 12 x 13 in (305 x 330 mm)
  • Page 130 Appendix D: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class B, EN 55022 Class B, EN 61000-3-2/-3-3, CISPR 22 Class B Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: EN 60950/IEC 60950-Compliant, UL Listed (USA), CUL Listed (Canada), TUV Certified (Germany), CE Marking (Europe)
  • Page 131 UPER ERVER 6013P-T Manual Notes...

Table of Contents
