X5DPR-8G2+ Quick Reference

Jumper Description
JBT1 CMOS Clear
JD1 Speaker Enable (Pins 6-7)
JPA1/JPA2 SCSI Channel A/B Termination Open (Terminated)
JD4 GLAN1/GLAN2 Enable/Disable
JP4 VGA Enable/Disable
JP9 Power Fail Alarm En/Disable
JP22 SCSI Enable/Disable
JP37/WD Watch Dog Enable/Disable
JP38 Front Side Bus Speed
Connector
ATX POWER
COM1/COM2
CPU1/CPU2
CPU CHS FAN
DIMM#1A-DIMM#3B
IDE#1/IDE#2
JA1
JA2
JD1
JF2
JP7
JP8
JP35
JP36
J15
J28
J29
GLAN1/2
OHLED
USB0/1
VGA
WOL
WOR
Chapter 5: Advanced Serverboard Setup
Description
Primary ATX Power Connector
COM1/COM2 Serial Port Connector
CPU 1 and CPU2 Sockets
CPU 1 & 2 Chassis Fan Headers
Memory (RAM) Slots
IDE #1/#2 Hard Disk Drive Connectors
LVD SCSI CH A Connector
LVD SCSI CH B Connector
JBT1/WD/IR/CIR/USB2/PWRLED/SPKR
Front Control Panel Connector
Floppy Disk Drive Connector
Third Power Supply Fail Header
Keylock Header
Alarm Reset Switch
Secondary ATX Power Connector
Keyboard Port
Mouse Port
Ethernet Ports
Overheat LED Header
Universal Serial Bus Ports
VGA Display (Monitor) Port
Wake-on-LAN Header
Wake-on-Ring Header
5-11
Default Setting
See Jumper Section
Closed (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Open (Disabled)
Pins 1-2 (Enabled)
Open (Disabled)
Pins 1-2 (Auto)
