4. Place the heatsink directly on the CPU so that the four mounting holes are aligned
with those on the chassis. Make sure the heatsink sits completely flat on the CPU
- if not completely flat, the space between the two will degrade the heat dissipation
function of the heatsink, which may cause the processor to overheat.
5. Screw in two diagonal screws (#1 and #2 or #3 and #4) until just snug (do not fully
tighten), then do the same with the remaining two diagonal screws. Finish by fully
tightening all four screws (see Figure 5-2).
6. If installing two processors, repeat these steps to install the second processor in
the CPU #2 slot.
Figure 5-1. 604-pin PGA Socket: Empty and with Processor Installed
Warning!
installing the CPU. If the lever is only partly raised, damage
!
to the socket or CPU may result.
Chapter 5: Advanced Serverboard Setup
Make sure you lift the lever completely when
5-3
