UPERSERVER 6013P-8+ User's Manual

Power LED/Speaker/NMI

On the JDI header, pins 1-3
for a power LED, pins 4-7 are for
the speaker and pins 8-9 are for
the NMI connection. See the table
on the right for speaker pin defini-
tions. Note: The speaker connec-
tor pins are for use with an exter-
nal speaker.
the onboard speaker, you should
close pins 6-7 with a jumper.
Third Power Supply Fail
Header
Connect a cable from your power
supply to the JP8 header to pro-
vide warning of power supply fail-
ure. This warning signal is
passed through the PWR_LED pin
on JF2 to indicate of a power fail-
ure on the chassis. See the table
on the right for pin definitions.
Note: This feature is only avail-
able when
Supermicro power supplies and
so does not apply to the 6013P-8+.

Chassis Intrusion

A Chassis Intrusion header is lo-
cated at JL1. Attach the appropri-
ate cable to inform you of a chas-
sis intrusion.
are
If you wish to use
using redundant
Speaker Co nnector Pin
Pin
Number Function
4
5 Key
6
7
T hird Power Sup ply Fail Header
Pin Definitions (JP8)
Pin
Number
1
2
3
4
5-16
Definitio ns (JD1)
Definition
+ R ed wire, Speaker data
No connection
Key
Speaker data
Definition
P/S 1 Fail Signal
P/S 2 Fail Signal
P/S 3 Fail Signal
R eset (from MB)
