Location and Standards
Table 3-3. Required PVHCE Equipment and Component Ratings
Required
Device
PV Link Generac Power Systems Inc.
Inverter Generac Power Systems Inc.
PV Modules
External STOP
Switch (optional)

Voltage and Frequency Trip Settings

The PWRcell Inverter ships from the factory in compli-
ance with UL 1741. The inverter nameplate
specifies compliance with applicable UL 1741 Supple-
ments (e.g. UL 1741-SA, UL 1741-SB). A PWRcell
Inverter compliant with UL 1741-SA is shipped with
default settings per IEEE 1547-2003. A PWRcell Inverter
compliant with UL 1741-SB is shipped with default set-
tings per IEEE 1547-2018. A list of the default values and
range of adjustability for UL 1741 SB tested functions is
found in Table 10-1. Where local Electric Utility require-
ments for smart inverters specify non-default inverter set-
tings (per the locally adopted IEEE 1547 grid standard),
follow the steps in the Set Inverter Grid Compliance sec-
tion of this manual.
NOTE: Use of Grid Profiles in compliance with local
Electric Utility smart inverter requirements may exceed
the tested range of adjustment for UL 1741-SB listed
inverters.
Table 3-4. Voltage and Frequency Trip Default Settings (UL 1741-SA)*

Voltage Trip

Trip Function
(% of nominal)
OV2
OV1
UV1
UV2
*This unit or system is provided with fixed trip limits and shall not be aggregated above 30 kW on a single point of common coupling.
Table 3-5. Voltage Trip and Frequency Trip Default Settings (UL 1741-SB)
Voltage Trip
Trip Function
(% of nominal)
OV2
OV1
UV1
UV2
12
Manufacturer
Various
Various
(Figure
Voltage
Clearing Time (s)
120 0.16
110 1
88 2
50 0.16
Voltage
Clearing Time (s)
120 0.16
110 13
88 21
50 2
Model
Max input voltage < 165 VDC, Type 4X rated, Operating
S2502HC Temperature Range -20°C to 70°C, Rapid Shutdown
Max Power: 7600 W. Type 3R rated, Operating Tempera-
XVT076A03
ture Range -20°C to 50°C. Not for roof mount.
Series connected panels with NEC temperature corrected
Various maximum Voc < 165 VDC, listed to UL 1703 and/or UL
61730-1 and UL 61730-2 (excluding Class 0 and Class 1)
Type 3R rated. Operating Temperature Range Range 40°C
Various
to 60°C, 12 VDC, 5 mA. Not for roof mount.
Voltage Trip
See
Table 3-4
trip settings. All over voltage and under voltage trip condi-
2-2)
tions result in a 300-second restart delay time after the
trip setting has been exceeded for the listed clearing
time.
The inverter is disconnected from the grid during this
300-second delay.

Frequency Trip

See
Table 3-4
quency trip settings. All over frequency and under fre-
quency trip conditions result in a 300-second restart
delay time after the trip setting has been exceeded for
the listed clearing time.
The inverter is disconnected from the grid during this
300-second delay.
Trip Function
OF1
UF1
Trip Function
OF2
OF1
UF1
UF2
Installation and Owner's Manual for Generac PWRcell Inverter
Required Ratings/Listings
Device Compatible.
and for the default fixed voltage
Table 3-5
and for the default fixed fre-
Table 3-5
Frequency Trip
Frequency (Hz) Clearing Time (s)
60.5
59.3
Frequency Trip
Frequency (Hz) Clearing Time (s)
62
61.2
58.5
56.5
0.16
0.16
0.16
300
300
0.16
