Generac Power Systems PWRcelP XVT076A03 Installation And Owner's Manual page 45

Access Code:
TOU Schedule:
Time Zone:
Cancel
Figure 6-17. Configuring TOU Schedule (4 of 4)
See Figure 6-18 and Figure
LCD will alternate between a TOU Scheduler Running
Screen and a Current System Mode screen. Both
screens will display the time until the next system change
and the mode the system will change to. The TOU
Schedule name will be listed at the bottom of the device
page.
REbus Beacon
TOU Scheduler
running
Next Change:
To:
Schedule:
Figure 6-18. Running.
REbus Beacon
TOU Scheduler
Priority Backup
Next Change:
To:
Schedule:
Figure 6-19. Current System Mode.
See and
Figure 6-20 Figure
the text above the power flow diagram will alternate
between Scheduler Active and the current system mode.
Installation and Owner's Manual for Generac PWRCell Inverter
57
1
4
Save
010112
6-19. When enabled, the
1h:37m
Self Supply
SDGE
010113
1h:37m
Self Supply
SDGE
010114
6-21. On the home page,
Figure 6-20. Scheduler Active
Figure 6-21. Current System Mode
Enabling Beacon TOU Scheduler
Once the TOU Schedule is set, the scheduler will auto-
matically enable itself and begin running. However, if the
scheduler becomes disabled for any reason, follow the
instructions below to re-enable the scheduler:
1. See Figure 6-22. Navigate to the REbus Beacon
device page and press the center button to enter
the device menu.
REbus Beacon
TOU Scheduler
disabled
To enable scheduler,
press center button
and select "Enable".
Figure 6-22. Enabling TOU Scheduler (1 of 2)
2. Highlight Enable and press the center button.
3. See
Figure 6-23. Arrow right to Confirm and press
the center button.
Commissioning
010115
010116
010118
41
