Troubleshooting
HEX
Code
Value
AC-Coupled PV is not supported on this inverter
0 0X7700
hardware version. Newer hardware is needed.
The PWRcell Inverter is not configured for islanding.
1 0X7701
This is required for AC-Coupled PV.
The PWRcell Inverter is configured for an incorrect
2 0X7702 number of ATSes. For AC-Coupled PV, 1 ATS should
be used.
AC Generator integration is not supported on this
3 0X7703 inverter hardware version. Newer hardware is
needed.
The PWRcell Inverter is not configured for islanding.
4 0X7704
This is required for AC Generator Integration.
The PWRcell Inverter is configured for an incorrect
5 0X7705 number of ATSes. For AC Generator Integration, 1 or
2 ATSes should be used.
The PWRcell Inverter is configured for 2 ATSs, but
'ACGenPower' is set to '0.'
6 0X7706
'ACGenPower' must be set to a non-0 value for AC
Generator Integration.
The PWRcell Inverter is configured for AC Generator
7 0X7707 Integration, but the installed PWRcell ATS(s) do not
have the correct controller.
'ACGenPower' setting is not configured between 9
8 0X7708
kW and 26 kW for AC generator integration.
The PWRcell Inverter is configured for both AC-Cou-
9 0X7709 pled PV and AC Generator Integration. Only one of
these features can be supported on a single system.
The PWRcell Inverter is configured for 3Ø applica-
A 0X770A tions. AC-Coupled PV and AC Generator Integration
are only supported with 1Ø applications.
The PWRcell Inverter is configured for 1 or more
B 0X770B
ATS but is not configured for islanding.
The PWRcell Inverter is configured for 1 or more
ATS but is also configured for 3Ø applications. An
C 0X770C
ATS may not be used for PWRcell installations on
3Ø services.
Bad input phase angle.
Phase angle has been detected to be 120 degrees
D 0X770D
or less. For single-phase services, this should be
180 degrees.
64
Configuration Error Codes
Description
Installation and Owner's Manual for Generac PWRCell Inverter
Corrective Action
Replace Inverter with an XVT model Inverter (Hardware version
1010 or later) to configure the PWRcell system for AC-Coupled PV.
Use the Inverter Mod. Settings to set "EnaIslanding" to "on". See
Configure Inverter Settings and Enable Inverter
mation.
Verify that only 1 ATS is installed.
Use the Inverter "Mod. Settings" to set 'NumTranSwtchs' to '1.' See
Configure Inverter Settings and Enable Inverter
mation.
Replace Inverter with an XVT model Inverter (Hardware version
1010 or later) in order to utilize AC Generator Integration.
Use the Inverter "Mod. Settings" to set 'EnaIslanding' to 'on.' See
Configure Inverter Settings and Enable Inverter
mation.
Verify the number of ATSes installed.
Use the Inverter Mod. Settings to set 'NumTranSwtchs' to '1' or '2'
to match the number of installed ATSes. See
Settings and Enable Inverter
Use the Inverter "Mod. Settings" to set 'ACGenPower' to the cor-
rect value based on the nameplate power rating of the integrated
generator. See Configure Inverter Settings and Enable Inverter
for more information.
Use the PWRcell ATS Controller Upgrade Kit (Model G0080060) to
allow AC Generator Integration with the installed PWRcell ATSes.
See PWRcell ATS Controller Upgrade Kit in the PWRcell ATS
Installation Manual for more information.
Adjust the value of 'ACGenPower' in "Mod. Settings" to match the
AC generator nameplate power value. 'ACGenPower' must be at
least 9 kW to enable Gen Integration.
Verify which configuration will be supported. Use the Inverter "Mod.
Settings" to configure the system accordingly:
If supporting AC Coupled PV, set 'ACGenPower' to '0.'
If supporting AC Generator Integration, set 'ACPVPower' to '0.'
See Configure Inverter Settings and Enable Inverter
information.
Install a single-phase inverter if the application is for a single phase
service. Otherwise, for three-phase services, use the Inverter
"Mod. Settings" to ensure 'ACPVPower' and 'ACGenPower' are
both set to '0' to indicate that neither AC-Coupled PV or AC Gener-
ator Integration will be used.
See Configure Inverter Settings and Enable Inverter
information.
Verify the presence of 1 or more ATS is installed on the system.
Use the Inverter "Mod. Settings" to configure the system accord-
ingly:
If 1 or more ATS is installed, set 'EnaIslanding' to 'on.'
If no ATS is installed, set 'NumTranSwtchs' to '0.'
See Configure Inverter Settings and Enable Inverter
information.
Install a single-phase PWRcell Inverter if the application is for a
single-phase service. Otherwise, for three-phase services, use the
inverter "Mod. Settings" to ensure 'NumTranSwtchs' is set to '0.'
See Configure Inverter Settings and Enable Inverter
information.
Check voltage measurement and make sure the system is wired
up correctly to a 120/240 Vac single-phase (Wye) service.
for more infor-
for more infor-
for more infor-
Configure Inverter
for more information.
for more
for more
for more
for more
