Commissioning
Setpoint
PLM_Channel
TargMaxImprtP -30,000 to +30,000 Watts
TargMinImprtP -30,000 to +30,000 Watts
EnaIslanding
NumTranSwtchs
ExtTransVolt 80 – 140 Volts
ExportOverride
CalOverride
CTTurnsRatio 1,500 – 3,000 Turns
EnaLoadShed
GridParInvrtrs
ACPVPower 0 – 7.6 kW
ACGenPower 0 – 26 kW
ACGenCtrlMode
36
Table 6-2. Inverter Settings
Range Default
0 – 12 1
0
0
on / off on
0 / 1 / 2 0
100
on / off off
on / off off
1,500
0 / 1 / 2 0
1 – 2 1
0
0
0 / 1 / 2 0
Channel for REbus communications. All devices in a system must use the
same channel (except REbus Beacon). Do not set equipment to channel 0
unless performing Commissioning Multiple Inverter
Maximum Threshold for importing power before the battery will discharge in
Self Supply Mode to offset.
Minimum power import maintained by charging the battery from the grid in
Self Supply Mode.
Allows system to go into island mode, providing backup power during a util-
ity service interruption. Turn this setting off for PV only installations.
Defines the number of external automatic transfer switches installed and
enables transfer switch controls.
For AC Coupled PV, this must be 1.
For AC Generator Integration, this must be 2.
Minimum voltage from the utility that must be present for the inverter to
reconnect back to the grid. If an ATS is installed, this will be the voltage
required for the inverter to control the ATS back to the normal (utility) posi-
tion.
Formerly called Zero Export, this setting will inhibit the PWRcell system
from exporting power to the grid. This setting is for temporary use and will
not satisfy CRD200 Import Only Compliance. See
(optional).
Overrides inverter logic for automatic detection of included Generac current
transformers (CTs).
Allows a different turns ratio to be set for specific CTs.
Select 1 if using PWRmanager and / or SMM devices to manage loads.
Select 2 if using the PWRcell ATS Controller to manage loads (with or with-
out SMMs). Do not use PWRmanager and PWRcell ATS Controller
together for load management.
This setting allows for two inverters to share one set of CTs. Set to 2 if daisy
chaining CTs between two inverters.
Do Not Use- Feature Not Supported. Power rating of the attached AC Cou-
pled PV array. Set this value to the cumulative power rating of AC Coupled
PV connected to this inverter. This value must reflect what is coupled. An
incorrect higher value will result in insufficient charging of the batteries; an
incorrect lower value will result in the possibility of an over voltage event.
Nameplate power rating of the AC coupled integrated generator. If no gen-
erator is integrated, leave at 0.
To set AC Generator Control Mode, select one of the three settings below.
See AC Generator Control Modes
Installation and Owner's Manual for Generac PWRCell Inverter
Description
Systems.
Set Export Override
for more info.
0 = Single Transfer
1 = Source Cycling
2 = Always On
