Commissioning
Rebus Beacon
Enable
Enable
Mod. Settings
Calibrate CTs
Cancel
RCPn: 00010003XXXX
< EXIT SCROLL > NEXT • SELECT
Figure 6-23. Enabling TOU Scheduler (2 of 2)
Disabling Beacon TOU Scheduler
The scheduler can be disabled at any time. To disable
the scheduler:
1. See Figure 6-24. Navigate to the Beacon device
page and press the center button to enter the
device menu.
REbus Beacon
TOU Scheduler
running
Next Change:
To:
Schedule:
Figure 6-24. Disabling TOU Scheduler (1 of 3)
2. Highlight Disable and press the center button.
3. See 6-25. Arrow right to Confirm and press
Figure
the center button.
Rebus Beacon
Enable
Disable
Mod. Settings
Calibrate CTs
Cancel
RCPn: 00010003XXXX
< EXIT SCROLL > NEXT • SELECT
Figure 6-25. Disabling TOU Scheduler (2 of 3)
4. See 6-26. The status line on the Beacon
Figure
device page will read Disabled.
NOTE: The system will remain in the current system
mode until the mode is changed manually or the sched-
uler is re-enabled.
42
Menu
Confirm
011140
1h:37m
Self Supply
SDGE
010113
Menu
Confirm
010117
REbus Beacon
TOU Scheduler
disabled
To enable scheduler,
press center button
and select "Enable".
Figure 6-26. Disabling TOU Scheduler (3 of 3)
Temporarily Overriding the TOU Scheduler
The scheduler can be temporarily overridden at any time
without disabling it. A manual override will apply until the
next regularly scheduled system mode change.
To temporarily override the scheduler:
1. Navigate to the system home page.
2. Press the center button.
3. Select the desired temporary system mode.
When the scheduler has been overridden:
•
Temporary Override will display on the home page,
alternating with the words Scheduler Active and
the name of the current system mode.
•
See 6-27. Running, Overridden will display
Figure
on the Beacon device page.
REbus Beacon
TOU Scheduler
running, overridden
Next Change:
To:
Schedule:
Figure 6-27. Overriding TOU Scheduler
•
The countdown timer on the Beacon device page
will indicate the remaining time until the next mode
change.
After the next scheduled mode change, the scheduler will
resume normal operation.
Disabling the TOU Scheduler in Anticipation of a Grid
Outage
In the event of an impending storm and potential outage,
top off the battery by disabling the scheduler and switch-
ing the system mode to priority backup or clean backup
mode.
To disable the TOU Scheduler:
Installation and Owner's Manual for Generac PWRCell Inverter
010118
1h:37m
Self Supply
