MICRO-EPSILON surfaceCONTROL 3D SC3200-80 Operating Instructions Manual page 14

Installation and Mounting
8,5
Fig. 8 Dimensional drawing sensor surfaceCONTROL 3D 32xx-80, dimensions in mm (inches)
surfaceCONTROL 3D SC3200 / SC3210
220 (8.66)
Z
X
75 (2.95)
65 (2.56)
50 (1.97)
Start expanded area
70 (2.76)
74 (2.91)
162.5 (6.40)
150 (5.91)
144.5 (5.69)
5.5 (.22)
0
End expanded area
49 (1.93)
0
Z
Y
50 (1.97)
47 (1.85)
44 (1.73)
110 (4.33)
120 (4.72) Start
130 (5.12) Mid
140 (5.51) End
150 (5.91)
53 (2.09)
56 (2.20)
Page 14
