3.8

Mechanical Data

Table 4 describes the mechanical characteristics of the Mercury+ PE3 base board. A 3D model ﴾PDF﴿ and
a STEP 3D model are available [5], [6].
Parameter
Size
Component height top
Component height bottom
Weight
Table 4: Mechanical Data
3.9

Mechanical Components

Table 5 describes the mechanical components present on the Mercury+ PE3 base board. The listed
elements are for reference only. Any other components that meet the requirements may be used.
Part Number
970080365
970070365
MPMS 003 0008 PH
Table 5: List of Mechanical Components
D‐0000‐420‐001
Value
171 112.4 mm
13.46 mm
4.2 mm
146 g ﴾without battery, module and bracket﴿
Manufacturer
Würth Elektronik
Würth Elektronik
B&F Fastener Supply
Description
5 plastic spacer bolt with female/female thread M3,
length 8 mm, beneath Mercury module
2 plastic spacer bolt with female/female thread M3,
length 7 mm, beneath Mercury module
5 Phillips pan head metric screws M3x8
