Feature
User I/Os
Powering options
Table 1: Base Board Features
3.3

Board Configuration and Product Models

Table 2 describes the standard base board configurations. Custom configurations are available. Contact
Enclustra for further information.
Product Model
ME‐PE3‐C
ME‐PE3‐4S‐C
Table 2: Standard Base Board Configuration
3.4 EN‐Numbers and Part Names
Every board is uniquely labeled, showing the EN‐number and serial number. An example is presented in
Figure 2.
Figure 2: Product Label
D‐0000‐420‐001
Description
Fan connector
40‐pin Anios pin header
2 Digital IO connectors ﴾micro‐coaxial connection﴿ shared with LEDs
1 User push button
6 User LEDs ﴾2 shared with digital IO connectors﴿
12 V barrel jack
USB Type‐C power
PCIe connector
4 SFP+
Connectors
–
QSFP+
Connectors Connectors
12 / 63
FMC HPC Temperature
‐10 to +75 C
‐10 to +75 C
Version 03, 11.07.2024
Range
