Chapter 4: BIOS Setup
PCH SATA Configuration
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced IntelRCSetup Security
PCH SATA Configuration
------------------------------------------------------------------------------------
SATA Controller [Enabled]
Configure SATA as [AHCI]
SATA Port 0 [Not Installed]
Port 0 [Enabled]
SATA Device Type [Hard Disk Drive]
[Not Installed]
SATA Port 1
Port 1 [Enabled]
SATA Device Type [Hard Disk Drive]
SATA Port 2 [Not Installed]
Port 2 [Enabled]
SATA Device Type [Hard Disk Drive]
SATA Port 3 [Not Installed]
Port 3 [Enabled]
SATA Device Type [Hard Disk Drive]
SATA Port 4 [Not Installed]
Port 4 [Enabled]
SATA Device Type [Hard Disk Drive]
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
SATA Controller
Enables or disables the SATA controller.
Configure SATA as
Configures the SATA as IDE or AHCI.
IDE This option configures the Serial ATA drives as Parallel ATA
physical storage device.
AHCI This option configures the Serial ATA drives to use AHCI
(Advanced Host Controller Interface). AHCI allows the storage
driver to enable the advanced Serial ATA features which will
increase storage performance.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
Enable or Disable SATA
Controller
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Port 0 to Port 4
Enables or disables Serial ATA port 0 to port 4.
SATA Device Type
Identifies what type of SATA device is connected.
