Chapter 4: BIOS Setup
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Advanced
Pc Health Status
: +42 C
CPU0 temperature
CPU1 temperature : +41 C
CPU Fan1 Speed : 5744 RPM
CPU Fan2 Speed : 3770 RPM
System Fan1 Speed : N/A
System Fan2 Speed : N/A
System Fan3 Speed : N/A
VCOREA : +1.800 V
VCOREB : +1.804 V
PVDDQ : +1.168 V
PVCCIO : +1.040 V
P3V3 : +3.312 V
P5V : +5.120 V
P12V : +12.192 V
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
CPU0 Temperature and CPU1 Temperature
Detects and displays the current CPU0 and CPU1 temperature.
CPU Fan1 Speed to CPU Fan2 Speed
Detects and displays the current CPU Fan1 and Fan2 speed.
System Fan1 to System Fan3 Speed
Detects and displays the current System Fan1, Fan2 and Fan3 speed.
VCOREA to P12V
Detects and displays the output voltages.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Serial Port Console Redirection
This section is used to configure the serial port that will be used for console
redirection.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Console Redirection
Enables or disables the console redirection.
33
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Advanced
COM0
[Enabled]
Console Redirection
► Console Redirection Settings
COM1
Console Redirection [Disabled]
► Console Redirection Settings
Legacy Console Redirection
► Legacy Console Redirection Settings
Serial Port for Out-of-Band Management /
Windows Emergency Management Services (EMS)
Console Redirection [Enabled]
► Console Redirection Settings
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Console Redirection Enable
or Disable
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
