Chapter 2: Jumpers and Connectors
Jumpers
TPM Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JTPMSEL1
1
3
Pin
Function
Enable some special
1-2 On
commands
Disable some special
2-3 On
commands
2-3 On: default
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
RTC Clear
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JCLRM1
1
3
Pin
Function
1-2 On
Normal
2-3 On
Clear CMOS
1-2 On: default
8
NSA 7136 User Manual
