Chapter 2: Jumpers and Connectors
LCM Header
Connector type: 1x6 6-pin header, 2.0mm
Connector location: J17
1
6
Pin
Definition
1
TX
3
GND
5
LED_KR_N
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
RX
4
5V
6
LED_KG_N
USB Headers
Connector type: 1x6 6-pin header, 2.0mm
Connector location: J10 and J21
1
6
Pin
Definition
1
5V
3
DP1
5
DP2
14
Pin
Definition
2
DN1
4
DN2
6
GND
NSA 7136 User Manual
