Chapter 2: Jumpers and Connectors
Console Type Selection (RTS/CTS)
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP13
1
3
Pin
Function
1-2 On
RTS to CTS
2-3 On
Normal
2-3 On: default
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Console Type Selection (RTS/CTS)
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP12
1
3
Pin
Function
1-2 On
RTS to CTS
2-3 On
Normal
2-3 On: default
11
NSA 7136 User Manual
