Chapter 4: BIOS Setup
IIO Configuration
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced IntelRCSetup Security
IIO Configuration
------------------------------------------------------------------------------------
EV DFX Features [Disable]
► IIO0 Configuration
► IIO1 Configuration
► IIO General Configuration
Intel VT for Directed I/O (VT-d)
►
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
EV DFX Features
Enables or disables the DFX Lock Bits to remain clear.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
Set this option to allow DFX
Lock Bits to remain clear
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
IIO0 Configuration
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced IntelRCSetup
IOU2 (IIO PCIe Port 1
IOU0 (IIO PCIe Port 2
IOU1 (IIO PCIe Port 3
No PCIe port active
► Socket 0 PcieD00F0 - Port 0/DMI
► Socket 0 PcieD01F0 - Port 1A
► Socket 0 PcieD02F0 - Port 2A
► Socket 0 PcieD02F2 - Port 2C
► Socket 0 PcieD03F0 - Port 3A
► Socket 0 PcieD03F2 - Port 3C
IIO0 Redriver Control
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
IOU2 (IIO PCIe Port 1)
Port Bifurcation settings for IOU 2.
IOU0 (IIO PCIe Port 2)
Port Bifurcation settings for IOU 0.
IOU1 (IIO PCIe Port 3)
Port Bifurcation settings for IOU 1.
No PCIe Port Active
Configures the workaround solution for ECO when the PCIe ports are not
active.
IIO0 Redriver Control
Configures the redriver options for IIO0.
44
Security Boot Save & Exit
[x8]
Selects PCIe port Bifurcation for
[x8x8] selected slot(s)
[x8x8]
[PCU Squelch exit ig. . .]
[Auto Detect]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
