Chapter 4: BIOS Setup
Serial Port 1 Configuration
This section is used to configure serial port 1.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Advanced
Serial Port 1 Configuration
Serial PortGSIO200 [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change SettingsGSIO60 [Auto]
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Serial PortGSIO200
Enables or disables the serial port.
Change SettingsGSIO60
Selects an optimal setting for the Super IO device.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Serial Port 2 Configuration
This section is used to configure serial port 2.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Serial PortGSIO200
Enables or disables the serial port.
Change SettingsGSIO60
Selects an optimal setting for the Super IO device.
32
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Advanced
Serial Port 2 Configuration
Serial PortGSIO200 [Enabled]
Device Settings IO=2F8h; IRQ=3;
Change SettingsGSIO60 [Auto]
Change SettingsGSIO60 [Standard Serial Por. . .]
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
