Chapter 3: System Setup
4. Place the LAN module into the tray making sure the connector side of the
module is at the rear side of the tray.
Connector
side
5. Secure the module in place with screws, and slide the tray back into the
bay.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Important:
Before using Optical fiber for transferring data, make sure
you have connected an approved Optical Transceiver Module.
User needs to install appropriate and UL approved Laser Class I
Transceivers, rated 3.3Vdc, max. 1W.
24
NSA 7136 User Manual
