Chapter 4: BIOS Setup

Intel RC Setup

This section is used to configure the processor and chipset settings.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced IntelRCSetup
RC Revision 1.1.5
Processor Configuration
►
► QPI Configuration
► Memory Configuration
► IIO Configuration
PCH Configuration
►
► Network Configuration
-------------------------------------------------------------------------------------
Setup Warning:
Setting items on this Screen to incorrect may cause system to
malfunction!
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Security Boot Save & Exit
Displays and provides option to
change the Processor Settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Processor Configuration
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced IntelRCSetup
Processor Configuration
-----------------------------------------------------------------------------------
► Per-Socket Configuration
Processor Socket Socket 0
Processor ID 000306F2*
Processor Frequency 2.600GHz
Processor Max Ratio 1AH
Processor Min Ratio 0CH
Microcode Revision 0000002E
L1 Cache RAM 768KB
L2 Cache RAM 3072KB
L3 Cache RAM 30720KB
Processor 0 Version Intel (R) Xeon (R) CPU E5
-2690 v3 @ 2.60GHz
Processor 1 Version Intel (R) Xeon (R) CPU E5
-2690 v3 @ 2.60GHz
Hyper-Threading [ALL] [Enable]
Execute Disable Bit [Enable]
Enable Intel TXT Supp [Disable]
VMX [Enable]
Enable SMX [Disable]
Hardware Prefetcher [Enable]
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Hyper-Threading [ALL]
Enables or disables hyper-threading technology.
Execute Disable Bit
When set to Disabled, it will force the XD feature flag to always return to 0.
Enable Intel ® TXT Support
Enables or disables Intel TXT support.
VMX
Enables or disables Virtual Machine Extensions.
Enable SMX
Enables or disables Secure Mode Extensions.
Hardware Prefetcher
Enables or disables the MLC streamer prefetcher.
39
Security Boot Save & Exit
Change Per-Socket Settings
Socket 1
| 000306F2
| 2.600GHz
| 1AH
| 0CH
| 0000002E
| 768KB
| 3072KB
| 30720KB
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
