Chapter 4: BIOS Setup
PCI Subsystem Settings
This section is used to configure the PCI.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Advanced
PCI Bus Driver Versio A5.01.05
PCI Devices Common Settings:
Above 4G Decoding [Disabled]
SR-IOV Support [Disabled]
► PCI Express Settings
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Above 4G Decoding
Enables or disables decoding of 64bit devices in 4G address space.
SR-IOV Support
Enables or disables SR-IOV support.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
PCI Express Settings
Enables or Disables 64bit
capable Devices to be Decoded in
Above 4G Address Space (Only
if System Supports 64 bit PCI
Decoding).
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Relaxed Ordering
Enables or disables the PCI Express device's relaxed ordering.
Extended Tag
When this function is enabled, it allows a device to use 8-bit tag field as a request.
No Snoop
Enables or disables the PCI Express device's no snoop option.
Maximum Payload
Selects the maximum TLP payload size of the PCI Express devices.
35
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Advanced
PCI Express Device Register Settings
Relaxed Ordering [Disabled]
Extended Tag [Disabled]
No Snoop [Enabled]
Maximum Payload [Auto]
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Enables or Disables PCI Express
Device Relaxed Ordering.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
