Chapter 4: BIOS Setup
QPI General Configuration
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced IntelRCSetup Security
QPI General Configuration
------------------------------------------------------------------------------------
► QPI Status
Link Speed Mode [Fast]
Link Frequency Select [Auto]
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
Link Speed Mode
Configures the link speed mode.
Link Frequency Select
Configures the QPI frequency.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
QPI Status Help
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
QPI Status
Displays information on the current QPI configuration.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced IntelRCSetup
QPI Status
------------------------------------------------------------------------------------
Number of CPU
Number of IIO
Current QPI Link Speed
Current QPI Link Frequency
QPI Global MMIO Low B
QPI Global MMIO High
QPI Pci-e Configuration
Version 2.17.1245. Copyright (C) 2015 American Megatrends, Inc.
42
Save & Exit
Security Boot
2
2
Fast
9.6 GT/s
90000000 / FBFFFFFF
00000000000 / 000FFFFFFF
80000000 / 10000000
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
