A malfunction is displayed if:
The device temperature is outside acceptable limits.
The device enclosure is open (tamper is triggered).
No connection with the hub or radio signal range extender via Jeweller.
The device battery is low.

Functionality testing

The Ajax system offers several tests to help select the device installation place.
Tests do not start immediately. However, the waiting time does not exceed the
duration of one "hub—device" polling interval. The polling interval can be
checked and con gured at hub settings (Hub → Settings
Jeweller/Fibra).
To run a test in the Ajax app:
1. Select the required hub.
2. Go to the Devices
3. Select KeyPad S Plus from the list.
4. Go to Settings
5. Select a test:
1. Jeweller Signal Strength Test
2. Signal Attenuation Test
6. Run the test.

Device placement

The device is designed for indoor use only.
tab.
.
→ Jeweller or
