Sound noti cations of malfunctions appear when the keypad indication is
nished. If multiple malfunctions occur in the system, the keypad will rst notify
about the loss of connection between the device and the hub rst.

Functionality testing

The Ajax system offers several types of tests to help select the correct
installation place for the devices. Tests do not start immediately. However, the
waiting time does not exceed the duration of one "hub-device" ping interval. Ping
interval can be checked and con gured at hub settings (Hub → Settings
Jeweller/Fibra).
To run a test, in the Ajax app:
1. Select the required hub.
2. Go to the Devices
3. Select KeyPad TouchScreen from the list.
4. Go to Settings
5. Run the Fibra Signal Strength Test

Device placement

The device is designed for indoor use only.
When choosing a location for the device, consider the parameters that affect its
operation:
Fibra signal strength.
Length of the cable used to connect KeyPad TouchScreen.
Follow these recommendations when designing the system project for an
object. Only professionals should design and install the Ajax system. The list of
authorized Ajax partners is
tab.
.
.
available here .
→
