Appendix A Specifications

DSAM Product Family Specifications

DSAM Product Family Specifications
Table 8 Product Specifications
Item
Frequency
Range
Accuracy
Tuning Resolution
Channel Bandwidth
Analog Level Measurement
Signal Types
a
Range
Resolution
Resolution Bandwidth
b
Accuracy
Carrier-to-Noise
Hum
56
Description
4 to 1,000 MHz
±10 ppm at 25° C (77° F)
Analog 10 kHz
Digital 50 kHz
Supports 6 or 8 MHz depending on
channel type
CW, video and audio
(NTSC, PAL, and SECAM)
-40 to +60 dBmV (typical)
0.1 dB
280 kHz
± 1.5 dB typical at 25° C (77° F)
30 to 45 dB ±2 dB
45 to 48 dB ±3 dB
Input @ >0 dBmV (up to 750MHz)
Input @ >6 dBmV (750 - 1000MHz)
For up to 5% hum:+/- 0.8%
Above 5% (up to 10%) +/- 1.0%
DSAM Product Family Quick-Start Guide Rev. 001
