Chapter 2 DSAM Meter Operation

Using AutoTests Mode

Using AutoTests Mode

Menu

40
Figure 28 DQI Mode Screen
The DQI display shows three minutes of data.
displays a point where over a minute passed before DQI
dropped to a point where BER might capture the issue.
One AutoTest measurement mode is indicated by the
softkey tab at the bottom of the display screen –
Autotests. The AutoTests measurement mode has a
menu of measurement items specific to that mode.
To view the Autotests menu
the Autotest key. Use the arrow keys to highlight the type
of AutoTests measurement you wish to perform and press
Enter to access that option.
The AutoTests tests are automated test sequences. The
following types of user-configurable AutoTest Install tests
are available on this meter:
– Combo AutoTest - a user-configured sequential
combination of Video Channels AutoTest and Cable
Modem AutoTest.
DSAM Product Family Quick-Start Guide Rev. 001
(Figure 29 on page
Figure 28
42), press
