Dosimag
Parameter overview with brief description
Parameter
Assign process variable
Volume unit
Totalizer operation mode
Failure mode
9.4.4 Resetting the measuring device
In the "Administration" submenu it is possible to reset the device.
Navigation
"Expert" menu → System → Administration
Administration
Parameter overview with brief description
Parameter
Device reset
9.5

Simulation

The "Simulation" submenu enables you to simulate, without a real flow situation, various
process variables in the process and the device alarm mode and to verify downstream signal
chains (switching valves or closed-control loops).
Navigation
"Diagnostics" menu → Simulation
Simulation
Endress+Hauser
Description
Select process variable for
totalizer.
Select volume unit.
Select totalizer calculation
mode.
Define totalizer behavior in
alarm condition.
Device reset
Description
Restart or reset device
manually.
Assign simulation process variable
Selection
• 0 = Off
• 1 = Volume flow
Unit choose list
• 0 = Net flow total
• 1 = Forward flow total
• 2 = Reverse flow total
• 0 = Stop
• 1 = Actual value
• 2 = Last valid value
Selection
• 0 = Cancel
• 2 = To delivery settings
• 1 = Restart device
Commissioning
Factory setting
1 = Volume flow
2 = m³
0 = Net flow total
0 = Stop
Factory setting
0 = Cancel
41
