Dosimag
6.2.1 Pin and socket assignment
Pulse/frequency/status output (option 3)
 7 Connection (option 3)
Option 3: Pulse/frequency/status output
RSE8 M12 × 1
A
2
3
1
4
8
7
5
6
B
2
3
1
4
8
7
5
6
Endress+Hauser
A
Pin Assignment
1 L+ Supply voltage: 24 V
2 + RX service interface (may not be connected during normal operation)
3 + TX service interface (may not be connected during normal operation)
4 L- Supply voltage: 24 V
5 + Pulse/frequency/status output (max. 30 V)
6 – Pulse/frequency/status output 1 (max. 25 mA)
7 – Pulse/frequency/status output 2 (max. 25 mA)
8 – GND service interface (may not be connected during normal operation)
Coding Plug/socket
A A: Socket
B: Plug
B
nominal voltage (20 to 30 V
DC
nominal voltage (20 to 30 V
DC
Electrical connection
A0023685
), 4.5 W
DC
), 4.5 W
DC
