Parameter overview with brief description
Parameter
Operating mode
Channel 2
Assign pulse output
Assign frequency output
Switch output function
Assign diagnostic behavior
Assign limit
Assign flow direction check
Assign status
Endress+Hauser
Failure mode
Failure frequency
Switch-on value
Switch-off value
Failure mode
Invert output signal
Description
Define the output as a
pulse, frequency or switch
output.
Select impulse with or
without time offset.
Select process variable for
pulse output.
Select process variable for
frequency output.
Select function for switch
output.
Select diagnostic behavior
for switch output.
Select process variable for
limit function.
Select process variable for
flow direction monitoring.
Select device status for
switch output.
Selection / User entry
• 0 = Off
• 2 = Pulse
• 3 = Automatic pulse
• 53 = Frequency
• 1 = Switch
• 0 = Off
• 1 = Redundant 0°
• 2 = Redundant 90°
• 3 = Redundant 180°
• 0 = Off
• 1 = Volume flow
• 0 = Off
• 1 = Volume flow
• 0 = Off
• 1 = On
• 2 = Diagnostic behavior
• 4 = Limit
• 3 = Flow direction check
• 5 = Status
• 0 = Alarm
• 2 = Alarm or warning
• 1 = Warning
1 = Volume flow
• 0 = Off
• 1 = Volume flow
0 = Low flow cut off
Commissioning
Factory setting
2 = Pulse
0 = Off
0 = Off
0 = Off
0 = Off
0 = Alarm
1 = Volume flow
1 = Volume flow
0 = Low flow cut off
