 4 Horizontal installation
1 Measuring electrodes
2 Liner
In the event of extreme heating (e.g. for CIP or SIP cleaning processes), we recommend
you install the measuring device in such a way that the transmitter part is pointing
downwards. This reduces the risk of the electronic components overheating.
 5 Recommended orientation in the event of extreme heating
Inlet and outlet runs
Endress+Hauser
A
5 × DN
≥
A
2 × DN
≥
Installation
1
2
A0003829
A0003830
A0016275
