Dosimag
Parameter overview with brief description
Parameter
Batch profile
Batch profile settings
The "Settings batch profile 1 to 6" submenu contains all the parameters that must be
configured for the configuration of the batch profiles.
Navigation
"Setup" menu → Batch output → Batch profile 1 to 6
Settings batch profile 1 to 6
Parameter overview with brief description
Parameter
Input selector
Batch unit
Batch quantity
Drip correction mode
Endress+Hauser
Description
Select suitable profile for
fluid configured by
customer.
Input selector
Batch unit
Batch quantity
Drip correction mode
Description
Select a process variable for
batch profile.
Select unit for process
variable of the batch profile.
Enter a quantity of selected
process variable for batch
profile.
Select a drip correction.
Selection
• 0 = Profile 1
• 1 = Profile 2
• 2 = Profile 3
• 3 = Profile 4
• 4 = Profile 5
• 5 = Profile 6
Selection / User entry
• 0 = Off
• 1 = Volume flow
Unit choose list
Signed floating-point
number
• 0 = Off
• 1 = Fixed time
• 2 = Fixed time or low
flow cut off
Commissioning
Factory setting
0 = Profile 1
Factory setting
0 = Off
4 = l
0 l
0 = Off
