4: Rack Information
60
Table 4-2 lists the technical specifications of the SGI 24U rack.
Table 4-2
Short (24U) Rack Technical Specifications
Characteristic
Height
Width
Depth
Weight (full)
Shipping length/width/height
Empty rack shipping weight
Full-rack total shipping weight 1,044 lbs (474.5 kg) approximate
Figure 4-5
SGI 24U (Short) Rack Rear View Example
Specification
50.25 in. (127.6 cm) [24U internal height]
24 in. (61 cm)
42 in. (106.7 cm)
775 lbs (352.3 kg) approximate
50x36x60.25 in. (127x91.4x153 cm) in packaging
269 lbs (122.3 kg) approximate (including pallet)
007-6402-001
