3: System Overview

Optional BaseIO SSDs

50
The BaseIO blade can be configured with one or two internal 1.8-inch solid state drives (SSDs).
These drives are located in the lower-left section of the BaseIO blade, as seen in Figure 3-6.
The SSDs can be configured as JBOD or RAID1. The RAID1 SSD pair is a software RAID1 and
two SSDs must be ordered with the system BaseIO to enable this configuration.
Figure 3-6 BaseIO Riser Enabled Blade Front Panel Example
SERIAL
VGA
LAN0
SSD1
SSD0
USB1
USB0
Optional SAS connectors
LAN1
BMC
USB3
USB2
