Removing and Replacing an IRU Enclosure Power Supply

Press latch
to release
007-6402-001
To remove and replace power supplies in an SGI UV 3000 IRU, you do not need any tools. Under
most circumstances a single power supply in an IRU can be replaced without shutting down the
enclosure or the complete system. In the case of a fully configured (loaded) enclosure, this may
not be possible.
Caution: The body of the power supply may be hot; allow time for cooling and handle with care.
Use the following steps to replace a power supply in the blade enclosure box:
1. Open the front door of the rack and locate the power supply that needs replacement.
2. Disengage the power-cord retention clip and disconnect the power cord from the power
supply that needs replacement.
Figure 6-1 Removing an Enclosure Power Supply
Removing and Replacing an IRU Enclosure Power Supply
