- Page 1 ® UV™ 30 System User Guide 007-6419-002...
- Page 2 Contractor/manufacturer is SGI, 46600 Landing Parkway, Fremont, CA 94538. TRADEMARKS AND ATTRIBUTIONS Silicon Graphics, SGI, and the SGI logo, and Supportfolio are trademarks or registered trademarks of Silicon Graphics International Corp. in the United States and/or other countries worldwide. ASPEED is a registered trademark of ASPEED. InfiniBand is a registered trademark of the InfiniBand Trade Association. Intel, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.
-
Page 3: Record Of Revision
Record of Revision Version Description May 2015 Original printing. July 2015 Added section to troubleshooting chapter. 007-6419-002... -
Page 5: Table Of Contents
Contents Record of Revision . . iii About This Guide . . xiii Audience. . xiii Chapter Descriptions . xiv Related Publications . . xv Conventions . . xv Product Support . . xvi Reader Comments . . xvi Introduction Server Chassis Features . - Page 6 Contents Reduced Airflow . 13 Mechanical Loading . . 13 Circuit Overloading . . 14 Reliable Ground . . 14 Install the System into a Rack . 14 Separate the Sections of the Rack Rails and Install Outer Rack Rails . .
- Page 7 Contents Perceived Boot Freezes (GPU Configurations) . . 43 Memory Errors . . 44 Technical Specifications . 45 BIOS Error Codes . . 49 007-6419-002...
- Page 9 Figures Figure 1-1 The SGI UV 30 Server . Figure 1-2 Front Chassis View . Figure 1-3 Rear Chassis View Figure 1-4 Serverboard Block Diagram . Figure 2-1 Installing the Onboard Battery . Figure 2-2 Improper Use of Server Rack and Railing .
- Page 11 Tables Tables Table 1-1 Server Chassis Features . Table 1-2 Serverboard Features . Table 4-1 Control Panel Components . . 25 Table 4-2 Universal Information LED States . . 25 Table 4-3 Drive Carrier LEDs . . 27 Table 4-4 Power Supply LED States .
-
Page 13: About This Guide
Audience This guide is written for owners, installers, system administrators, and users of SGI UV 30 computer systems. It is written with the assumption that the reader has a good working knowledge of computers and computer systems. -
Page 14: Chapter Descriptions
About This Guide Chapter Descriptions The following topics are covered in this guide: • Chapter 1, “Introduction” Provides an overview of SGI UV 30 server components. • Chapter 2, “System Safety” Provides system safety information. • Chapter 3, “Server Installation”... -
Page 15: Related Publications
About This Guide Related Publications The following SGI documents are relevant to the SGI UV 30 server: • SGI Foundation Software User Guide (007-6410-xxx) • SGI Performance Suite release notes • SGI InfiniteStorage series documentation • Man pages You can obtain SGI documentation, release notes, or man pages in the following ways: •... -
Page 16: Product Support
About This Guide Product Support SGI provides a comprehensive product support and maintenance program for its products. SGI also offers services to implement and integrate Linux applications in your environment. • Refer to http://www.sgi.com/support/ • If you are in North America, contact the Technical Assistance Center at +1 800 800 4SGI or contact your authorized service provider. -
Page 17: Introduction
Chapter 1 Introduction The SGI UV 30 server is a 2U rackmount server (see Figure 1-1) It has two main subsystems: the 2U server chassis and a quad-processor serverboard. Figure 1-1 The SGI UV 30 Server This chapter describes the server using the following topics: •... -
Page 18: Server Chassis Features
1: Introduction Server Chassis Features Table 1-1 describes the main features of the SGI UV 30 server chassis. Table 1-1 Server Chassis Features Feature Description System power The chassis features a redundant 2000W power supply consisting of two hot-pluggable, Titanium-level power modules (96% efficiency). The power redundancy allows the system to operate if one power supply module fails or is replaced. -
Page 19: Figure 1-2 Front Chassis View
Server Chassis Features Figure 1-2 shows the noteworthy components on the front of the server chassis. Figure 1-2 Front Chassis View Figure 1-3 shows the noteworthy components on the rear chassis panel. Figure 1-3 Rear Chassis View 007-6419-002... -
Page 20: Serverboard Features
1: Introduction Serverboard Features ® At the heart of the SGI UV 30 server is a quad-processor serverboard based on the Intel C612 chipset, designed to provide maximum performance. Table 1-2 describes the major features of the serverboard. Table 1-2... -
Page 21: Figure 1-4 Serverboard Block Diagram
Serverboard Features Figure 1-4 Serverboard Block Diagram 007-6419-002... -
Page 22: Additional Hardware Components
1: Introduction Additional Hardware Components In addition to the serverboard and chassis, the following hardware components have been included with the server: • Four conventional riser cards • One Ultra riser card • A plastic air shroud • Four 8-cm system cooling fans •... -
Page 23: System Safety
Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SGI UV 30 system from damage, as follows: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet. -
Page 24: Figure 2-1 Installing The Onboard Battery
2: System Safety • Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarities (see Figure 2-1). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. -
Page 25: General Safety Precautions
General Safety Precautions Follow these rules to ensure general safety: • Keep the area around the SGI UV 30 system clean and free of clutter. • The system weighs approximately 52 lbs (23.6 kg.) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight. -
Page 26: Esd Precautions
2: System Safety ESD Precautions Caution: Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other. An electrical discharge is created to neutralize this difference. The discharge can damage electronic components and printed circuit boards. The following measures are generally sufficient to neutralize this difference before contact is made to protect your equipment from ESD: •... -
Page 27: Server Installation
Chapter 3 Server Installation This chapter provides a quick setup checklist to get the SGI UV 30 server operational. Unpack the System Inspect the shipping container used for the server and note if it was damaged in any way. If the server shows damage, file a damage claim with the carrier who delivered it. -
Page 28: Choose A Setup Location
• The SGI UV 30 server weighs 52 lbs (23.6 kg). Always use proper lifting techniques when your move the server. Always get the assistance of another qualified person when you install the sever in a location above your shoulders. -
Page 29: Server Precautions
Rack Mounting Considerations Server Precautions • Review the electrical and general safety precautions in Chapter 2, “System Safety.” • Determine the placement of each component in the rack before you install the rails. • Install the heaviest server components in the bottom of the rack first, and then work up. •... -
Page 30: Circuit Overloading
3: Server Installation Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern. -
Page 31: Figure 3-1 Separating And Installing The Rack Rails
Install the System into a Rack Rail Assembly Extending the Rails Quick- Release Tab Separating the Inner Rail Extension Figure 3-1 Separating and Installing the Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the chassis extend between 30 inches and 33 inches. -
Page 32: Install The Inner Rails
3: Server Installation 6. Press the button where the two outer rails are joined to retract the smaller outer rail. 7. Hang the hooks of the rails onto the rack holes and if desired, use screws to secure the front of the outer rail onto the rack. -
Page 33: Figure 3-2 Installing The Inner Rails
Install the System into a Rack Figure 3-2 Installing the Inner Rails 007-6419-002... -
Page 34: Install The Server In A Rack
Install the Server in a Rack Warning: The SGI UV 30 server weighs 52 lbs (23.6 kg). Always use proper lifting techniques when your move the server. Always get the assistance of another qualified person when you install the sever in a location above your shoulders. Failure to do so may result in serious personal injury or damage to the equipment. -
Page 35: Figure 3-3 Installing The Server In A Rack
Install the System into a Rack Figure 3-3 Installing the Server in a Rack Note: The figure above is for illustration purposes. Always install servers to the rack in a bottom-to-top fashion. 007-6419-002... -
Page 36: Check The Serverboard Setup
3: Server Installation Check the Serverboard Setup After you install the server in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Before operating the server for the first time, it is important to remove any protective film covering the top of the chassis. -
Page 37: Figure 3-4 Accessing The Inside Of The Chassis
Check the Serverboard Setup Figure 3-4 Accessing the Inside of the Chassis 007-6419-002... -
Page 38: Checking The Components And Setup
3: Server Installation Checking the Components and Setup You may have two or four processors already installed in your serverboard. Ensure that the serverboard is populated per your order. Your server system comes with system memory already installed. Make sure all DIMMs are fully seated in their slots. -
Page 39: System Monitoring
Chapter 4 System Monitoring There are several buttons and LEDs on the control panel, drive carriers, and power supplies to keep you constantly informed of the overall status of the system. As shown in Figure 4-1, the control panel is on the left handle of the chassis. Figure 4-1 Front Control Panel This chapter describes the functions of the buttons and LEDs and the appropriate responses you... -
Page 40: Control Panel Components
4: System Monitoring Control Panel Components Figure 4-2 shows the components of the control panel. Figure 4-2 Control Panel Components 007-6419-002... -
Page 41: Table 4-1 Control Panel Components
Control Panel Components Table 4-1 describes the functions of the components. Table 4-1 Control Panel Components Component Description The main power button is used to apply or remove power from the power supply to the server. Turning off system power with this button removes the main power but keeps standby power supplied to the system. - Page 42 4: System Monitoring Table 4-2 Universal Information LED States (continued) LED State Condition Solid red An overheat condition has occurred. For an overheat condition, consider the following: - Ensure that the ambient room temperature is not too warm. - Check the routing of cables and make sure all fans are present and operating.
-
Page 43: Drive Carrier Leds
Drive Carrier LEDs Drive Carrier LEDs Each hard drive carrier has two LEDs. Table 4-3 describes the functions of the two LEDs. Table 4-3 Drive Carrier LEDs Color Blinking Pattern Behavior for Device Activity LED Blue Solid on SAS/NVMe drive installed Blue Blinking I/O activity... -
Page 44: Power Supply Led
4: System Monitoring Power Supply LED There is a single bi-color LED (green/amber) to indicate the power supply status. Table 4-4 describes the different states of the LED. Table 4-4 Power Supply LED States LED State Power Supply (PS) State No AC power to any PS. -
Page 45: Chassis Maintenance
Chapter 5 Chassis Maintenance For warranty and safety considerations, SGI designates the following chassis components as customer-replaceable units: • Power supplies • Fans • Disk drives The disk drives and power supplies are hot-swappable; that is, you can replace them without powering down the server. -
Page 46: Before You Start
5: Chassis Maintenance Before You Start Warning: Review the warnings and precautions listed in this manual before setting up or servicing this chassis. These include the items described in Chapter 2, “System Safety.” Tools and Supplies Needed • Phillips (cross head) screwdriver •... -
Page 47: Figure 5-1 Accessing The Inside Of The Chassis
Removing the Chassis Cover 3. Press both release tabs at the same time to unlock the cover and slide the cover to the rear. 4. Lift the cover from the chassis. Figure 5-1 Accessing the Inside of the Chassis 007-6419-002... -
Page 48: Replacing A Power Supply
5: Chassis Maintenance Replacing a Power Supply The server chassis includes a redundant, hot-pluggable 2000W power supply, consisting of two power modules. They have an auto-switching capability, which enables them to automatically sense and operate at a 100V–240V input voltage. If either of the two power supply modules fail, the other module will take the full load and allow the system to continue operation without interruption. -
Page 49: Figure 5-3 Replacing A Power Supply
Replacing a Power Supply Figure 5-3 Replacing a Power Supply 007-6419-002... -
Page 50: Replacing Disk Drives
5: Chassis Maintenance Replacing Disk Drives Caution: Except for short periods of time while swapping hard drives, do not operate the server with the hard drive slots empty. The server has twenty-four hot-swappable 2.5" drive bays. The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis. -
Page 51: Figure 5-4 Removing Hdd Carrier From Chassis
Replacing Disk Drives Figure 5-4 Removing HDD Carrier from Chassis 007-6419-002... -
Page 52: Figure 5-5 Removing Dummy Drive From Carrier
5: Chassis Maintenance Figure 5-5 Removing Dummy Drive from Carrier 007-6419-002... -
Page 53: Installing A Drive Into A Carrier
Replacing Disk Drives Installing a Drive into a Carrier Use the following procedure to install a drive into a carrier. Install a new drive into the carrier with the printed circuit board side facing down so that the mounting holes in the drive align with those in the carrier. Figure 5-6. -
Page 54: Replacing System Fans
5: Chassis Maintenance Replacing System Fans Fan speed is controlled by system temperature via IPMI. If a fan fails, the remaining fan will ramp up to full speed and the overheat/fan fail LED on the control panel will turn on. Replace any failed fan at your earliest convenience with the same type and model. -
Page 55: Figure 5-7 System Fans
Replacing System Fans Figure 5-7 System Fans 007-6419-002... -
Page 57: Troubleshooting
Chapter 6 Troubleshooting This chapter describes troubleshooting for the problems listed below. Chapter 4 describes use of the control panel to monitor the overall system status and the status of specific components. Chapter 5, “Chassis Maintenance” describes how to replace defective components. •... -
Page 58: If The System Does Not Power Up
6: Troubleshooting If the System Does Not Power Up If the system will not power up when the front power button is pushed, use the following checklist to identify common sources for the problem: • Make sure that both ends of each system power cable are firmly connected to the power supply and the corresponding power source(s) or power distribution unit (PDU). -
Page 59: No Video After System Power Up
No Video After System Power Up No Video After System Power Up If the system powers up and appears to be booting normally but no video is present, try the following basic solutions: • Confirm your monitor is plugged in and switched on. •... -
Page 60: Memory Errors
6: Troubleshooting Memory Errors If your system experiences memory related errors, try these basic troubleshooting steps to resolve or better identify the problem: • Confirm that the power supply LED is not indicating an error. • Shut the system down, remove the covers over the serverboard and make sure that all the DIMM modules are properly and fully installed. -
Page 61: A Technical Specifications
Appendix A Technical Specifications Table A-1 lists allowable ranges for temperature, humidity, and altitude for the SGI UV 30 server. Table A-1 Temperature, Humidity, and Altitude Specifications Attribute Specification Rate of Change Constraints While Product Operating º º Temperature – Up to 1500m (5000ft) -
Page 62: Table A-2 Miscellaneous System Specifications
A: Technical Specifications Table A-2 lists other key specifications for the server. Table A-2 Miscellaneous System Specifications Attribute Specification Processors – Up to four Intel Xeon E5-4600 v3 Series processors – LGA2011 sockets (Socket R3) Chipset Intel PCH C612 chipset ®... - Page 63 Table A-2 Miscellaneous System Specifications (continued) Attribute Specification Power Supply – 2 x Hot-pluggable 1U PSU 2000W – Rated Output Power: 2000W redundant power – Rated Output Voltages: +12V (62.5A at 100–127VAC, 83A at 200–240VAC), +12Vsb (2.1A) Regulatory Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN Compliance 61000-3-2/-3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN...
-
Page 65: Bios Error Codes
Appendix B BIOS Error Codes During Power-On Self-Test (POST) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process. The error messages normally appear on the screen. Fatal errors are those which will not allow the system to continue the boot-up procedure.
