Identification

2.1

Device designation

The "Prosonic Flow 90" flowmeter system consists of the following components:
x Transmitter Prosonic Flow 90
x Measuring sensors Prosonic Flow W and U
2.1.1

Nameplate of the transmitter

ENDRESS+HAUSER
PROSONIC FLOW 90
Order Code:
1
Ser.No.:
TAG No.:
16-62VDC/20-55VAC
2
50-60Hz
I-OUT (HART), f-OUT
3
STATUS-IN, STATUS-OUT
4
Fig. 1: Nameplate specifications for the "Prosonic Flow 90" transmitter (example)
1 Ordering code / serial number: See the specifications on the order confirmation for the meanings of the
individual letters and digits.
2 Power supply / frequency: 16...62 V DC / 20...55 V AC / 50...60 Hz
Power consumption: 15 VA / W
3 Available inputs and outputs:
I-OUT (HART): with current output (HART)
f-OUT: with pulse/frequency output
STATUS-IN: with status input (auxiliary input)
STATUS-OUT: with status output
4 Reserved for information on special products
5 Ambient temperature range
6 Degree of protection
90WA1-XXXXXXXXXXXX
12345678901
ABCDEFGHJKLMNPQRST
15VA/W
i
-20°C (-4°F) < Tamb < +60°C (+140°F)
Pat. UK EP 618 680
Pat. US 5,479,007
