Brief operating instructions
2
Brief operating instructions
These brief operating instructions explain how to configure your measuring device
quickly and easily:
Please read the safety instructions through carefully.
Connecting the transmitter
Install the sensors using the transmitter software. Therefore connect the transmit-
ter first to the power supply.
Switching on the measuring device
Description of the startup sequence visible on the on-site display after switching
on the transmitter.
Display and operating elements
A brief overview of the different display and operating elements to allow you to
start quickly .
Installing the flowrate measuring sensors Prosonic Flow W (Clamp On)
Installing the flowrate measuring sensors Prosonic Flow U (Clamp On)
Installing the flowrate measuring sensors Prosonic Flow W (Insertion)
Safety instructions
M
M
M
M
Installing the sensors
M
PROline Prosonic Flow 90
Page 7
Page 35
+ – + – + – + –
1 2 20 21 22 23 24 25 26 27
Page 59
Page 41
+48.25 ml/min
3
+3702.6 m
Esc
+
-
E
Page 17 ff.
