PROline Prosonic Flow 90
Endress+Hauser
10.5
Dimensions of W sensors (Insertion version)
A
Fig. 57:
Dimensions of W sensors (Insertion version)
A = View A
a = Pipe outer diameter (defined by the application)
b = Sensor spacing determinable using Quick Setup
c = Path length determinable using Quick Setup
10 Technical data
A
a
~ 150
99
