40-pin Samtec / USB-C to USB-C (HSSTP) Switch

Through this hardware switch, you can conveniently connect

ARM HSSTP II Active Probe

and a host PC via a standard USB-C connection

to NVIDIA Orin device (connection marked as ORIN USB-C) at the same time. This switch is optional

and must be ordered separately.

A use case is that an application is programmed by the PC-based flash programming utility

through the USB-C connection, and later, the application is debugged using the ARM HSSTP II Active

Probe. Refer to the

Technical Note NVIDIA Orin: USB port functionality switching

the switching can be automated.

Ordering code

IEA-SWITCH-SAM40USBC

for a use case where
