EtherNet/IP Implementation

8. EtherNet/IP Implementation
Plese refer to the Netbiter Argos Administration Manual on configuring EtherNet/IP.

8.1 Client

Connection Type
UCMM (Class 1 and 3 connection not supported)
Adapter Timeout
1000 ms
Services
The following services are implemented:
Code Service Name
0x0E Get_Attribute_Single
0x10 Set_Attribute_Single
Addressing
Class, Instance, Attribute

8.2 Adapter

8.2.1 Identity Object (0x01)
Class Attributes
No attributes are implemented.
Instances
Instance 1 is implemented with the following attributes:
ID Access
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
Services
The following services are implemented:
Code Class
0x01 No
0x0E No
Netbiter EasyConnect Gateway User Manual
Name
Vendor ID
Device Type
Product Code
Revision
Status
Serial Number
Product Name
Instance Service Name
Yes Get_Attributes_All
Yes Get_Attribute_Single
Value
90
100
85
1
1
...
Netbiter
