Connections
2.4.6 USB Connector
The USB connector can be used to connect locally to the Netbiter EC310/350 for firmware
upgrades, configuration or troubleshooting.
See also "Local Configuration" on page 37.
USB connector
2.4.7 3G/GPRS Antenna Connector (Netbiter EC350 only)
The 3G/GPRS antenna connector on the front of the unit is a standard female SMA screw
connector. A stub antenna is supplied as standard, and optional external antennas are
available from your supplier.
2.4.8 GPS Antenna Connector (Netbiter EC350 only)
The Netbiter EC350 has a built‐in GPS receiver. An external GPS antenna (not included)
should be connected to the female SMA screw connector on the underside of the unit. The
connector also provides power for active GPS antennas.
Netbiter EasyConnect Gateway User Manual
2G/3G antenna connector
GPS antenna connector
Doc: HMSI-168-92 Rev: 3.00
15
