Verify Operation

Anybus Communicator - EtherNet/IP to EtherCAT MDevice
9. Verify Operation
Before You Begin
Ensure that the Communicator is connected to your PC, to a power supply and to the OT network.
See Installation (page 12).

9.1. Communicator Status Monitor

On the Home page, you can get a quick overview of the network and the Communicator operating status.
Figure 39. Home page
Gateway Status
Overview the Communicator LED indications remotely.
Refer to Communicator LED Indicators.
Node Status
Overview the status for each node added to the subnetwork.
Network Status and Settings
Overview communication status and the current networks settings.
SCM-1202-218 Version 1.0 Page 43 of 61
