5. About Anybus Communicator

5.1. EtherCAT MDevice Communication

5.1.1. EtherCAT MDevice Building Blocks

The following building blocks are used to describe the subnetwork communication.
Node
Figure 1. Nodes on a EtherCAT subnetwork
A node represents a single EtherCAT SubDevice on the EtherCAT subnetwork.
Each node can be associated with a number of process data objects.
