CVM-B150-ITF-HF
7�6�4�- MODBUS COMMUNICATIONS
Configuration of the LonWorks parameters
Configuration variable
Flag Service Pin
Neuron ID
(65)
The following functions are implemented for this variable:
(64)
Function 0x04: reading registers.
Function 0x10: Writing multiple registers.
For this variable Function 0x04 is implemented.
(65)
7�6�5�- LIST OF LONWORKS LOGS
Note: The binary files and setup file can be downloaded from Circutor's website.
Variable
Current L1
Current L2
Current L3
Phase-Phase Voltage V12
Phase-Phase Voltage V23
Phase-Phase Voltage V31
Phase-Neutral Voltage L1
Phase-Neutral Voltage L2
Instruction Manual
Table 131:Modbus memory map: LonWorks communications module
Address
E678
(64)
E67A - E67C
Name
nvo_Ph1Current
Code
02
Name
nvo_Ph2Current
Code
07
Name
nvo_Ph3Current
Code
12
Name
nvo_Ph2PhU12
Code
22
Name
nvo_Ph2PhU23
Code
23
Name
nvo_Ph2PhU31
Code
24
Name
nvo_Ph2NU1
Code
01
Name
nvo_Ph2NU2
Code
06
Valid data margin
0 - 1 ( Function 0x10)
1 (Function 0x04)
Decimal value
Variable type
SNVT_amp_ac (139)
Resolution
1
Variable type
SNVT_amp_ac (139)
Resolution
1
Variable type
SNVT_amp_ac (139)
Resolution
1
Variable type
SNVT_volt_ac (138)
Resolution
1
Variable type
SNVT_volt_ac (138)
Resolution
1
Variable type
SNVT_volt_ac (138)
Resolution
1
Variable type
SNVT_volt_ac (138)
Resolution
1
Variable type
SNVT_volt_ac (138)
Resolution
1
Default value
-
-
Unit
A 1
Values
0..65,534
Unit
A 2
Values
0..65,534
Unit
A 3
Values
0..65,534
Unit
V 12
Values
0..65,534
Unit
V 23
Values
0..65,534
Unit
V 31
Values
0..65,534
Unit
V 1
Values
0..65,534
Unit
V 2
Values
0..65,534
251
