7�5�- MODBUS/TCP BRIDGE COMMUNICATIONS MODULE
The M-CVM-AB-Modbus TCP (Bridge) is a communications module for connecting the CVM-B 150
devices to a Modbus/TCP network and as an Ethernet to RS-485 gateway.
Modbus/TCP is a communications protocol designed for enabling industrial devices to communicate
with each other on Ethernet networks using TCP/IP protocols.
Basically, Modbus/TCP encapsulates a Modbus frame within a TCP frame, making it possible to
configure and monitor a device via the Internet.
The communications module is also equipped with an RS-485 gateway.
7�5�1�- CONNECTION TERMINALS
7�5�2�- LEDs
240
Table 124:List of terminals, Modbus TCP ( Bridge ) communications module�
1: Ethernet
2: A(+), RS-485
Figure 281: Modbus TCP ( Bridge) communications module terminals
Table 125: List of LEDs, Modbus TCP (Bridge) communications module�
LED Status
On
LINK / ACT
Off
Blinking light
On
SPEED
Off
LINK/ACT
Figure 282: LEDs Modbus TCP� (Bridge)
Terminals in the device
3: B(-), RS-485
4: S, GND for RS-485
2 3
1
Function
Device connected to the network
Device disconnected from the network
Activity on the bus
100 BT
10 BT
SPEED
CVM-B150-ITF-HF
4
Instruction Manual
