CVM-B150-ITF-HF
7�4�4�3�- Status of the analogue inputs
The following functions are implemented for these variables:
Function 0x04: reading registers.
Table 120: Modbus memory map: Analogue inputs, expansion modules (Table 6)�
Status of the analogue inputs: Slot 1
Configuration variable
Status Input 1
Status Input 2
Status Input 3
Status Input 4
Table 121: Modbus memory map: Analogue inputs, expansion modules (Table 7)�
Status of the analogue inputs: Slot 2
Configuration variable
Status Input 1
Status Input 2
Status Input 3
Status Input 4
Table 122: Modbus memory map: Analogue inputs, expansion modules (Table 8)�
Status of the analogue inputs: Slot 3
Configuration variable
Status Input 1
Status Input 2
Status Input 3
Status Input 4
Table 123: Modbus memory map: Analogue inputs, expansion modules (Table 9)�
Status of the analogue inputs: Slot 4
Configuration variable
Status Input 1
Status Input 2
Status Input 3
Status Input 4
Instruction Manual
Address Valid data margin
D390 – D391
D392 – D393
D394 – D395
D396 – D397
Address Valid data margin
D778 - D779
D77A - D77B
D77C - D77D
D77E - D77F
Address Valid data margin
DB60 - DB61
DB62 - DB63
DB64 - DB65
DB66 - DB67
Address Valid data margin
DF48 - DF49
DF4A - DF4B
DF4C - DF4D
DF4E - DF4F
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
